Chapter 42 Other API | PCI-DMC-A01 / PCI-DMC-B01

Revised March, 2012

42-5

42.5 _DMC_01_enable_dda_mode

FORMAT

I16 PASCAL _DMC_01_enable_dda_mode (U16 CardNo, U16 enable)


Purpose

Enables DDA Table writing function.


Parameters

Name

Data Type

Unit

Description

CardNo

U16

Number Unit

Interface card CardNo are 0~15.

Enable

U16

Selection

0: Disable DDA Table writing function.
1: Enable DDA Table writing function.

Bit0:Node1
Bit1:Node2
Bit2:Node3
Bit3:Node4
Bit4:Node5
Bit5:Node6
Bit6:Node7
Bit7:Node8
Bit8:Node9
Bit9:Node10
Bit10:Node11
Bit11:Node12


Example

U16 CardNo = 0;
U16 Enable = 5; // Enable Node1,3

I16 status = _DMC_01_enable_dda_mode (CardNo, Enable);
