Chapter 20 2-Axis Arc Interpolation Motion Control API | PCI-DMC-A01 / PCI-DMC-B01

Revised March, 2012

20-37

20.18 _DMC_01_start_v3_spiral_xy

FORMAT

I16 PASCAL _DMC_01_start_v3_spiral_xy (U16 CardNo, U16* NodeID, U16* SlotID,
I32 Center_X, I32 Center_Y, I32 spiral_interval, I32 spiral_angle, I32 StrVel, I32 ConstVel, I32
EndVel, F64 TPhase1, F64 TPhase2, U16 m_curve,U16 m_r_a)


Purpose

2-axis spiral motion with EndVel added (Known conditions: center coordinates for X and Y
axes).
※Values of StrVel and EndVel can be greater than MaxVel.


Parameters

Name

Data Type

Unit

Description

CardNo U16

Number

Unit

Node ID of card used for motion
displacement along X-axis and Y-axis

NodeID

U16*

Number Unit

Holds Node ID sets used for carrying out
spiral motion
NodeID[0] holds 1st set of Node ID
NodeID[1] holds 2nd set of Node ID

SlotID

U16*

Number Unit

Slot ID

Center_X

I32

Number of pulses Center X-coordinate on specified axis

Center_Y I32

Number

of

pulses

Center Y-coordinate on specified axis

spiral_interval

I32

Number of pulses Relative distance between spirals

spiral_angle I32

Number

Total angle of spiral motion (one revolution
is 360 degrees)

StrVel

I32

Pulses per second

Starting velocity parameter

ConstVel

I32

Pulses per second

Constant velocity

EndVel

I32

Pulses per second

End velocity

TPhase1 F64 Second

Time

from StartVel to ConstVel

TPhase2

F64

Second

Time from ConstVel to EndVel

m_curve U16 Selection

1: T-curve
2: S-curve

m_r_a

U16

Selection

0: Relative motion displacement
1: Absolute motion displacement
