Chapter 29 4-Channel Analog Output Remote I/O Module API | PCI-DMC-A01 / PCI-DMC-B01

29-6

Revised March, 2012

29.5 _DMC_01_rm_04da_set_output_enable

FORMAT

I16 PASCAL _DMC_01_rm_04da_set_output_enable (U16 CardNo, U16 NodeID,U16 SlotID,
U16 ChannelNo, U16 Enable)


Purpose

Enables/disables pin output.


Parameters

Name

Data Type

Unit

Description

CardNo U16

Number

Unit

CardNo is between 0~15

NodeID

U16

Number Unit

Node ID is (0~12)

SlotID U16

Number

Unit

0

ChannelNo

U16

Number Unit

Channel ID is between 0~3

Enable U16

Selection

0: Output disable
1: Output enable. Set and send the output

value to target


Example

U16 CardNo = 0;
U16 NodeID = 1;
U16 SlotID = 0;
U16 ChannelNo = 3;
U16 Enable = 1; //Enable

I16 status = _DMC_01_rm_04da_set_output_enable (CardNo, NodeID, SlotID, ChannelNo,

Enable);
