Chapter 37 Security API | PCI-DMC-A01 / PCI-DMC-B01

37-14

Revised March, 2012

37.17 _misc_slave_user_data_buffer_write

FORMAT

I16 PASCAL _misc_slave_user_data_buffer_write (U16 CardNo, U16 NodeID, U16 SlotID
U16 Address, U32 Data)


Purpose

Writes data to buffer.


Parameters

Name

Data Type

Unit

Description

CardNo U16

Number

Unit

CardNo is between 0~15

NodeID

U16

Selection

Node ID

SlotID

U16

Number Unit

Slot ID

Address

U16

Number

Position to write to

Data

U32

Number

Data to write


Example

U16 CardNo=0;
U16 NodeID=1;
U16 SlotID=0;
U16 Address;
U32 Data;

I16 status = _ misc_slave_user_data_buffer_write (CardNo, NodeID, SlotID, Address, Data);
