——— CONVERTER OPERATION ———
5
18
SPEED REGULAT
[118] Speed ref [rpm]
[236] Speed reg output [% ]
[322] Lock speed reg
[242] Enable spd reg
[348] Lock speed I
[1016] Aux spd fun sel
[444] Prop filter [ms]
Self tuning
[1029] Fwd-Rev spd tune
[1048] Test T curr lim [%]
[1027] Start
[1014] Inertia [kg*m*m*]
[1030] Inertia Nw [kg*m*m*]
[1015] Friction [N*m]
[1031] Friction Nw [N*m]
[87] Speed P [%]
[1032] Speed P Nw [%]
[88] Speed I [%]
[1033] Speed I Nw [%]
[1028] Take val
Spd zero logic
[123] Enable spd=0 I
[124] Enable spd=0 R
[125] Enable spd=0 P
[126] Spd=0 P gain [%]
[106] Ref 0 level [FF]
Speed up
[445] Speed up gain [%]
[446] Speed up base [ms]
[447] Speed up filter [ms]
Droop function
[696] Droop gain [%]
[697] Droop filter [ms]
[698] Load comp [%]
[700] Droop limit [FF]
[699] Enable droop
Inertia/loss cp
[1014] Inertia [kg*m*m]
[1015] Friction [N*m]
[1013] Torque const [N*m/A]
[1012] Inertia c filter [ms]
