GEI-100332Ga
——— PARAMETER LISTS ———
10
64
Parameter No. Position
Adap I gain 3 [%] 193 ADD SPEED FUNCT \ Adaptive spd reg
Adap I gain 4 [%] 1463 ADD SPEED FUNCT \ Adaptive spd reg
Adap joint 1 [%] 186 ADD SPEED FUNCT \ Adaptive spd reg
Adap joint 2 [%] 187 ADD SPEED FUNCT \ Adaptive spd reg
Adap P gain 1 [%] 188 ADD SPEED FUNCT \ Adaptive spd reg
Adap P gain 2 [%] 190 ADD SPEED FUNCT \ Adaptive spd reg
Adap P gain 3 [%] 192 ADD SPEED FUNCT \ Adaptive spd reg
Adap P gain 4 [%] 1462 ADD SPEED FUNCT \ Adaptive spd reg
Adap reference [FF] 183 ADD SPEED FUNCT \ Adaptive spd reg
Adap selector 1464 ADD SPEED FUNCT \ Adaptive spd reg
Adap speed 1 [%] 184 ADD SPEED FUNCT \ Adaptive spd reg
Adap speed 2 [%] 185 ADD SPEED FUNCT \ Adaptive spd reg
An in 1 target 295 I/O CONFIG \ Analog inputs \ Analog input 1
An in 2 target 296 I/O CONFIG \ Analog inputs \ Analog input 2
An in 3 target 297 I/O CONFIG \ Analog inputs \ Analog input 3
Arm inductance [mH] 454 CURRENT REGULAT
Arm resistance [ ] 453 CURRENT REGULAT
Auto capture 388 ADD SPEED FUNCT
Auto tune inp 1 259 START UP \ Analog inputs \ Analog input 1
Auto tune inp 1 259 I/O CONFIG \ Analog inputs \ Analog input 1
Auto tune inp 2 260 START UP \ Analog inputs \ Analog input 2
Auto tune inp 2 260 I/O CONFIG \ Analog inputs \ Analog input 2
Auto tune inp 3 261 START UP \ Analog inputs \ Analog input 3
Auto tune inp 3 261 I/O CONFIG \ Analog inputs \ Analog input 3
Aux spd fun sel 1016 SPEED REGULAT
Base current [%] 313 START UP \ Overload contr
Base current [%] 313 FUNCTIONS \ Overload contr
Base omega [rpm] 1163 OPTIONS \ TORQUE WINDER \ Diam Calculatio
Bitword pad A 519 SPEC FUNCTIONS \ Pad Parameters
Bitword pad B 536 SPEC FUNCTIONS \ Pad Parameters
Close loop comp 1208 OPTIONS \ TORQUE WINDER \ Torque calculat \ Comp calculat
Closed loop En 1214 OPTIONS \ TORQUE WINDER \ Torque calculat \ Comp calculat
Closing speed [rpm] 1262 FUNCTIONS \Brake control
Constant J comp [%] 1172 OPTIONS \ TORQUE WINDER \ Torque calculat \ Comp calculat
Control mode 253 START UP
Control mode 253 REG PARAMETERS \ In use values
Control word 55 DRIVECOM
Curr limit state 349 LIMITS \ Current limits
Current lim red [%] 13 LIMITS \ Current limits
Dancer constant [mm] 798 OPTIONS \ PID \ Diameter calc
Dec delta speed [FF] 29 START UP
Dec delta speed [FF] 29 RAMP \ Deceleration
Dec delta speed [FF] 29 DRIVECOM \ Deceleration
Dec delta speed0 [FF] 661 FUNCTIONS \ Multi ramp fct \ Ramp 0 \ Deceleration 0
Dec delta speed1 [FF] 31 FUNCTIONS \ Multi ramp fct \ Ramp 1 \ Deceleration 1
Dec delta speed2 [FF] 33 FUNCTIONS \ Multi ramp fct \ Ramp 2 \ Deceleration 2
Dec delta speed3 [FF] 35 FUNCTIONS \ Multi ramp fct \ Ramp 3 \ Deceleration 3
Dec delta time [s] 30 START UP
Dec delta time [s] 30 RAMP \ Deceleration
Dec delta time [s] 30 DRIVECOM \ Deceleration
Dec delta time 0 [s] 662 FUNCTIONS \ Multi ramp fct \ Ramp 0 \ Deceleration 0
Dec delta time 1 [s] 32 FUNCTIONS \ Multi ramp fct \ Ramp 1 \ Deceleration 1
Dec delta time 2 [s] 34 FUNCTIONS \ Multi ramp fct \ Ramp 2 \ Deceleration 2
