GEI-100332Ga
——— FUNCTION DESCRIPTION ———
6
48
6.11.2 Speed base value, Full load current
CONFIGURATION
[45] Speed base value [FF]
[179] Full load curr [A]
[175] Max out voltage [V]
Parameter description No.
Value
Standard
Configuration min max
Factory
American
Factory
European
Speed base value [FF] 45 1 16383 1500 1500 -
Full load curr [A] 179 0.1 P465 P465 P465 -
Max out voltage [V] 175 20 999 400 400 -
Speed base value The Speed base value is defined by the unit specified in the factor function. It is the
reference value for all speed values (reference values, adaptive speed regulation.) given
as a percentage, and corresponds to 100% of the speed. Changing this parameter is only
possible when the drive is disabled (Enable drive = Disabled). The Speed base value
does not define the maximum possible speed, which in some cases can be formed from
the addition of several reference values. This is defined with Speed max amount.
Full load curr The Full load curr (FLC) parameter is defined in Amps. It corresponds to 100 % of
the current limit. The settings for the current limit and the overload function are based
on this active current value.
Max out voltage Max armature voltage supplied from the drive. When it has been set as Flux reg mode
“Voltage control”, Max out voltage corresponds to the crossover point. This parameter
has an influence on the intervention threshold of the “Overvoltage” message.
6.11.3 Configuration of the OK relay (Terminals 35,36)
CONFIGURATION
[412] Ok relay funct
Parameter description No.
Value
Standard
Configuration min max
Factory
American
Factory
European
Ok relay funct
Drive healthy (0)
Ready to Start (1)
412 0 1 0 0 -
Ok relay func This parameter defines the condition in which the relay contact will close.
Drive healthy The contact will close when the drive is supplied with voltage
and when there are no failure alarms.
Ready to start The contact closes when the following conditions are ful-
filled: - The drive has a voltage supply
- There are no failure alarms present
- The drive is enabled with Enable drive.
