DV-300 Adjustable Speed Drives
——— PARAMETER LISTS ———
10
49
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
Input 2 sign
Positive
Negative
390 U16 0 1 1 1 ü R/W
1
0
- R/W
1
0
Input 3 sign
Positive
Negative
391 U16 0 1 1 1 ü R/W
1
0
- R/W
1
0
Spd threshold
Speed exceeded
Speed not exceeded
393 U16 0 1 - R
0
1
QD
L
H
R
0
1
Set speed
Speed not ref. val.
Speed = ref. val.
394 U16 0 1 - R
0
1
QD
L
H
R
0
1
Speed zero thr
Drive not rotating
Drive rotating
395 U16 0 1 - R
0
1
QD
L
H
R
0
1
Motor pot up
No acceleration
Acceleration
396 U16 0 1 R/W
0
1
ID
L
H
R/W
0
1
Motor pot down
No deceleration
Deceleration
397 U16 0 1 R/W
0
1
ID
L
H
R/W
0
1
Jog +
No jog forwards
Forwards jog
398 U16 0 1 R/W
0
1
ID
L
H
R/W
0
1
Jog -
No backwards jog
Backwards jog
399 U16 0 1 R/W
0
1
ID
L
H
R/W
0
1
Speed sel 0
Value 2 0 not selected
Value 2 0 selected
400 U16 0 1 0 0 - R/W
0
1
ID
L
H
R/W
0
1
Speed sel 1
Value 2 1 not selected
Value 2 1 selected
401 U16 0 1 0 0 - R/W
0
1
ID
L
H
R/W
0
1
Speed sel 2
Value 2 2 not selected
Value 2 2 selected
402 U16 0 1 0 0 - R/W
0
1
ID
L
H
R/W
0
1
Ramp sel 0
Value 2 0 not selected
Value 2 0 selected
403 U16 0 1 - R/W
0
1
ID
L
H
R/W
0
1
Ramp sel 1
Value 2 1 not selected
Value 2 1 selected
404 U16 0 1 - R/W
0
1
ID
L
H
R/W
0
1
Overld available
Overload not possible
Overload possible
406 U16 0 1 - - - R
0
1
QD
L
H
R
0
1
Overload state
Current limit value
Current > limit value
407 U16 0 1 - - - R
0
1
QD
L
H
R
0
1
Ser answer delay 408 U16 0 900 0 0 ü R/W -- ---
Ok relay funct
Drive healthy
Ready to Start
412 I16 0 1 0 0 ü R/Z
0
1
- -
Speed fbk sel
Encoder 1
Encoder 2
Tacho
Armature
414 U16 0 3 1 1 ü R/Z
0
1
2
3
- R
Encoder 1 pulses 416 Float * 600 9999 1024 1024 ü R/Z - R
