——— FUNCTION DESCRIPTION ———
6
96
Acc delta time 1 It defines together with Acc delta speed 1 the acceleration ramp 1. Defined in seconds.
S acc t const 1 Defines the acceleration curve for S-shape ramp 1. Defined in ms.
Dec delta speed1 It defines together with Dec delta time 1 the deceleration ramp 1. Defined by the units
specified in the factor function.
Dec delta time 1 It defines together with Dec delta speed 1 the deceleration ramp 1. Defined in seconds.
S dec t const 1 Defines the deceleration curve for S-shape ramp 1. Defined in ms.
Acc delta speed2 It defines together with Acc delta time 2 the acceleration ramp 2. Defined by the units
specified in the factor function.
Acc delta time 2 It defines together with Acc delta speed 2 the acceleration ramp 2. Defined in seconds.
S acc t const 2 Defines the acceleration curve for S-shape ramp 2. Defined in ms.
Dec delta speed2 It defines together with Dec delta time 2 the deceleration ramp 2. Defined by the units
specified in the factor function.
Dec delta time 2 It defines together with Dec delta speed 2 the deceleration ramp 2. Defined in seconds.
S dec t const 2 Defines the deceleration curve for S-shape ramp 2. Defined in ms.
Acc delta speed3 It defines together with Acc delta time 3 the acceleration ramp 3. Defined by the units
specified in the factor function.
Acc delta time 3 It defines together with Acc delta speed 3 the acceleration ramp 3. Defined in seconds.
S acc t const 3 Defines the acceleration curve for S-shape ramp 3. Defined in ms.
Dec delta speed3 It defines together with Dec delta time 3 the deceleration ramp 3. Defined by the units
specified in the factor function.
Dec delta time 3 It defines together with Dec delta speed 3 the deceleration ramp 3. Defined in seconds.
S dec t const 3 Defines the deceleration curve for S-shape ramp 3. Defined in ms.
Ramp sel 0 Ramp selection with the significance 2 0 (Bit 0). Parameter can only be used in conjunc-
tion with Ramp sel 1.
High Significance 2 0 selected
Low Significance 2 0 not selected
Ramp sel 1 Ramp selection with the significance 2 1 (Bit 1). Parameter can only be used in conjunc-
tion with Ramp sel 0.
High Significance 2 1 selected
Low Significance 2 1 not selected
See in the following table and graph the interaction between the selection and the ramp
Ramp
sel 0
Ramp
sel 1
Ramp 0 Low Low
Ramp 1 High Low
Ramp 2 Low High
Ramp 3 High High
GD6242g
Table 6.14.4.1: Ramp selection
In order to activate the Multiramp function, it must be enabled with the Enab multi rmp parameter.
The ramp required is selected via the Ramp sel 0 and Ramp sel 1 signals. When the selection is made via the
terminal strip, it is possible to select only one digital input. This configuration enables only the ramp time selected.
Another ramp can be selected at any time. If this happens during an acceleration or deceleration phase, the refer-
ence value will then follow the new ramp. The ramp parameter are defined via the keypad or serial line.
