GEI-100332Ga
——— FUNCTION DESCRIPTION ———
6
144
PI controls
[765] PI P gain PID
[764] PI I gain PID
[695] PI steady thr
[731] PI steady delay
[793] P init gain PID
[734] I init gain PID
[779] PI central v sel
[776] PI central v1
[777] PI central v2
[778] PI central v3
[784] PI top lim
[785] PI bottom lim
[783] PI integr freeze
[771] PI output PID
[418] Real FF PID
Parameter description No.
Value
Standard
Configuration min max
Factory
American
Factory
European
PI P gain PID 765 0.00 100.00 10.00 10.00
PI I gain PID 764 0.00 100.00 10.00 10.00
PI steady thr 695 0 10000 0 0
PI steady delay 731 0 60000 0 0
P init gain PID 793 0.00 100.00 10.00 10.00
I init gain PID 734 0.00 100.00 10.00 10.00
PI central v sel 779 0 3 1 1 *
PI central v1 776 PI bottom lim PI top lim 1.00 1.00
PI central v2 777 PI bottom lim PI top Lim 1.00 1.00
PI central v3 778 PI bottom lim PI top Lim 1.00 1.00 **
PI top lim 784 PI bottom lim 10.00 10.00 10.00
PI bottom lim 785 -10.00 PI top lim 0.0 0.0
PI integr freeze
OFF (0) / ON (1)
783 0 1 0 0 *
PI output PID 771 0 1000 x PI top limit 1000 1000
Real FF PID 418 -10000 +10000 0 0
* This function can be set on a digital programmable input
** This parameter can be set on an analog programmable input
PI P gain PID Proportional gain of PI block
PI I gain PID Integral gain of PI block
PI steady thr Threshold feed-forward survey. If Feed-fwd PID is less than PI steady thr the integral
regulation will be frozen, the proportional gain assumes the value set in P init gain PID.
When Feed-fwd PID overcomes the threshold, the integral regulation with the gain
set in I init gain PID will be enabled. The PI block will mantain the gains P init gain
PID and I init gain PID for the time preset through PI steady delay. Once this delay
is over, they will be brought automatically to PI P gain PID and PI I gain PID.
