GEI-100332Ga
——— FUNCTION DESCRIPTION ———
6
218
Speed min neg Defines the minimum speed for the anti-clockwise rotation of the motor (with 6KDV3...
Q4...). A lower value than the defined value is not possible, regardless of the reference
value. The function has an effect on the input of the ramp (see Figure 6.4.1.1). The value
to be entered is based on the factor function.
Speed max neg Defines the maximum speed for the anti-clockwise rotation of the motor (with 6KDV3...
Q4...). The function has an effect on the input of the speed regulator, and therefore takes
into consideration the reference value that comes from the ramp as well as the those that
are entered directly (see Figure 6.4.2.1). The value to be entered is based on the factor
function.
6.18.4 Acceleration / Deceleration
DRIVECOM
Acceleration
[21] Acc delta speed [FF]
[22] Acc delta time [s]
Deceleration
[29] Dec delta speed [FF]
[30] Dec delta time [s]
Quick stop
[37] QStp delta speed [FF]
[38] QStp delta time [s]
Parameter description No.
Value
Standard
Configuration min max
Factory
American
Factory
European
Acc delta speed [FF] 21 0 232-1 100 100
Acc delta time [s] 22 0 65535 1 1
Dec delta speed [FF] 29 0 232-1 100 100
Dec delta time [s] 30 0 65535 1 1
QStp delta speed [FF] 37 0 232-1 1000 1000
QStp delta time [s] 38 0 65535 1 1
Quick stop
Quick stop (0)
No Quick stop (1)
343 0 1 No Quick stop No Quick stop
Acc delta speed Has the same unit as the ramp reference value and is based on the factor function.
Acc delta time Is defined in seconds. The ramp output follows the reference value directly if “0 s” is
entered.
Dec delta speed Has the same unit as the ramp reference value and is based on the factor function.
Dec delta time Is defined in seconds. If “0 s” is entered, the ramp output follows the reference value
directly.
Qstp delta speed Has the same unit as the ramp reference value and is based on the factor function.
