GE Industrial Solutions DV-300 DC Drive Users Manual User Manual
Page 430
GEI-100332Ga
——— PARAMETER LISTS ———
10
36
Parameter
No.
Format
Value
Access via
min
max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
DRIVECOM \ Speed amount
Speed min amount [FF]
1
U32
0
232-1
0
0
ü
R/Z
-
-
Speed max amount [FF]
2
U32
0
232-1
5000
5000
ü
R/Z
-
-
DRIVECOM \ Speed min/max
Speed min pos [FF]
5
U32
0
232-1
0
0
ü
R/Z
-
-
Speed max pos [FF]
3
U32
0
232-1
5000
5000
ü
R/Z
-
-
Speed min neg [FF]
6
U32
0
232-1
0
0
ü
R/Z
-
-
Speed max neg [FF]
4
U32
0
232-1
5000
5000
ü
R/Z
-
-
DRIVECOM \ Acceleration
Acc delta speed [FF]
21
U32
0
232-1
100
100
ü
R/W
-
-
Acc delta time [s]
22
U16
0
65535
1
1
ü
R/W
-
-
DRIVECOM \ Deceleration
Dec delta speed [FF]
29
U32
0
232-1
100
100
ü
R/W
-
-
Dec delta time [s]
30
U16
0
65535
1
1
ü
R/W
-
-
DRIVECOM \ Quick stop
QStp delta speed [FF]
37
U32
0
232-1
1000
1000
ü
R/W
-
-
QStp delta time [s]
38
U16
0
65535
1
1
ü
R/W
-
-
Quick stop
Quick stop
No Quick stop
343
U16
0
1
No Quick
stop
No Quick
stop
-
R/W
0
1
-
-
DRIVECOM \ Face value fact
Face value num
54
I16
1
32767
1
1
ü
R/Z
-
R
Face value den
53
I16
1
32767
1
1
ü
R/Z
-
R
DRIVECOM \ Dimension fact
Dim factor num
50
I32***
1
65535
1
1
ü
R/Z
-
R
Dim factor den
51
I32***
1
231-1
1
1
ü
R/Z
-
R
Dim factor text
52
Text
rpm
rpm
ü
R/Z
-
-
DRIVECOM
Speed base value [FF]
45
U32***
1
16383
1500
1500
ü
R/Z
-
R
Speed input perc [%]
46
I16
-32768
+32767
0
0
ü
R/W
-
R/W
Percent ref var [%]
116
I16
-32768
+32767
ü
R
-
R
Act percentage [%]
120
I16
-32768
+32767
ü
R
-
R
SERVICE
Password 2
* When the parameter is accessed by Opt2-A/PDC the format is U16
** When the parameter is accessed by Opt2-A/PDC the format is I16
*** When the parameter is accessed by Opt2-A/PDC the lower word of the parameter is considered
