GEI-100332Ga
——— PARAMETER LISTS ———
10
28
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
Base current [%] 313 U16 0 P312
< 100
100 80 ü R/W - -
Overload time [s] 310 U16 0 65535 60 30 ü R/W - -
Motor ovrld preal. 1289 U16 0 1 - - ü R - -
Motor I2t accum 655 Float 0,00 100,00 - - ü R - -
Drive ovrld preal. 1438 U16 0 1 - - ü R - -
Drive I2t accum 1439 FLOAT 0,00 100,00 - - ü R - -
Pause time [s] 311 U16 0 65535 540 300 ü R/W - -
Overld available
Overload not possible
Overload possible
406 U16 0 1 - - - R
0
1
QD
L
H
R
0
1
Overload state
Current limit value
Current > limit value
407 U16 0 1 - - - R
0
1
QD
L
H
R
0
1
FUNCTIONS \ Stop control
Stop mode
OFF
Stop & speed 0
Fast stp & spd 0
Fst / stp & spd 0
626 U16 0 3 Stop &
Speed 0
Stop &
Speed 0
ü R/Z
0
1
2
3
- -
Spd 0 trip delay [ms] 627 U16 0 40000 0 0 ü R/W - -
Trip cont delay [ms] 628 U16 0 40000 0 0 ü R/W - -
Jog stop control
OFF
ON
630 U16 0 1 OFF OFF ü R/Z
0
1
- -
FUNCTIONS \Brake control
Enable Torque pr 1295 I16 0 1 Disabled Disabled ü R/W - -
Closing speed [rpm] 1262 U16 0 200 30 30 ü R/W - -
Torque delay [ms] 1293 I16 0 30000 3000 3000 ü R/W - -
Torque proving [%] 1294 I16 0 200 75 75 ü R/W - -
Actuator delay [ms] 1266 U16 0 30000 1000 1000 ü R/W - -
FUNCTIONS \ I/n curve (Taper curr lim)
I/n curve
(Taper curr limit)
Enabled
Disabled
750 U16 0 1 0 0 ü R/Z
1
0
- -
I/n lim 0 [%]
(Taper lim 0 [%])
751 U16 0 200 0 0 ü R/Z - -
I/n lim 1 [%]
(Taper lim 1 [%])
752 U16 0 200 0 0 ü R/Z - -
I/n lim 2 [%]
(Taper lim 2 [%])
753 U16 0 200 0 0 ü R/Z - -
I/n lim 3 [%]
(Taper lim 3 [%])
754 U16 0 200 0 0 ü R/Z - -
I/n lim 4 [%]
(Taper lim 4 [%])
755 U16 0 200 0 0 ü R/Z - -
I/n speed [rpm]
(Tapered speed [rpm])
756 U16 0 P162 0 0 ü R/Z - -
SPEC FUNCTIONS \ Test generator
Generator access
Not connected
T current ref
Flux ref
Ramp ref
Speed ref
58 U16 0 5 Not conn. Not conn. ü R/Z
0
2
3
4
5
- -
Gen frequency [Hz] 59 Float 0.1 62.5 0.1 0.1 ü R/W - -
