The deceleration of the drive is defined as a quotient of the parameters Dec delta speed and Dec delta time (see Figure
6.6.1.1). As for the four quadrant converters (6KDV3 ... Q4...) it is the same for both directions of rotation.
The Quick Stop function provides the possibility of a second deceleration ramp for the emergency braking of
the drive. The ramp output in this case is not set to zero immediately but after a set time. The deceleration of
the drive via the Quick Stop function is defined as the quotient of the Qstp delta speed and Qstp delta time
parameters. As for the four quadrant converters (6KDV3 ... Q4...) it is the same for both directions of rotation.
This ramp is activated by the functions Fast stop (via terminals) and Quick stop.
6.6.2 Ramp shape and control commands
RAMP
[18]
Ramp shape
[19]
S shape t const [ms]
[663]
S acc t const [ms]
[664]
S dec t const [ms]
[20]
Ramp +/- delay [ms]
[673]
Fwd-Rev
[245]
Enable ramp
[344]
Ramp out = 0
[345]
Ramp in = 0
[373]
Freeze ramp
Parameter description
No.
Value
Standard
Configuration
min
max
Factory
American
Factory
European
Ramp shape
Linear (0)
S-Shaped (1)
18
0
1
Linear (0)
Linear (0)
-
S shape t const [ms]
19
100
3000
300
300
-
S acc t const [ms]
663
100
3000
300
300
-
S dec t const [ms]
664
100
3000
300
300
-
Ramp +/- delay [ms]
20
0
65535
100
100
-
Fwd-Rev
No direction (0)
Fwd direction (1)
Rev direction (2)
No direction (3)
673
0
3
1
1
-
Forward sign
293
0
1
0
0
-
Reverse sign
294
0
1
0
0
-
Enable ramp
Enabled (1)
Disabled (0)
245
0
1
Enabled (1)
Enabled (1)
-
Ramp out = 0
Active (0)
Not active (1)
344
0
1
Not active (1) Not active (1)
*
Ramp in = 0
Active (0)
Not active (1)
345
0
1
Not active (1) Not active (1)
*
Freeze ramp
Active (0)
Not active (1)
373
0
1
Not active (1) Not active (1)
*
Ramp +
Acc.CW + Dec. anti-CW (1)
Other states (0)
346
0
1
-
-
Digital output 1 *
Ramp -
Acc.anti-CW + Dec. CW (1)
Other states (0)
347
0
1
-
-
Digital output 2 *
* This function can be assigned to one of the programmable digital inputs.
** This parameter can be assigned to a programmable digital output.
*** This function can be assigned to one of the programmable analog outputs.
