DV-300 Adjustable Speed Drives
——— WIRING PROCEDURES ———
4
5
Table 4.3.5: Cable size for power field terminals U1, V1, C1, D1
American
European
max cable section
[mm2]
AWG
Tightening torque
[Nm]
6KDV3017...
6KDV3020...
0.2...4
24...10
0.5...0.8
6KDV3035...
6KDV3040...
6KDV3056...
6KDV3070...
6KDV3088...
6KDV3110...
6KDV3112...
6KDV3140...
6KDV3148...
6KDV3185...
6KDV3224...
6KDV3280...
6KDV3280...
6KDV3350...
6KDV3336...
6KDV3420...
6KDV3400...
6KDV3500...
6KDV3450...
6KDV3650...
6KDV3560...
6KDV3770...
6KDV3800...
6KDV310H
6KDV3850
GD0130g
The following sizes are provided with terminal blocks:
U/V/W/C/D:
AWG 5 - 3/0 (16-95 mm
2
), stranded Cu
PE:
AWG 5 - 1 (16-50 mm
2
), stranded Cu
The following AWG and torque are required for field wiring:
Device
AWG
Tightening torque [Nm]
6KDV3088…
2
12
6KDV3112…
1/0
12
6KDV3148…
3/0
12
earth
-
12
GD0136g-a
n
ote
!
When connecting the converter, a 9.5 mm (3/8 in.) spacing between uninsulated live parts of
opposite polarity should be mantained.
n
ote
!
The DV-300 converters are UL listed only when used with the above mentioned terminal kits.
Table 4.3.6: Cable size for fans, signals, thermistors and regulation supply
Terminals
Max connection cable section
Tightening torque
[Nm]
flexible [mm
2
]
multi-core [mm
2
]
AWG
PE
2.5...10
2.5...10
12...8
2
U2, U3, V2, V3, 35, 36, 75, 76, 78, 79
0.14...1.5
0.14...2.5
26...14
0.5
T0140g
