2.7.2 Encoder / Tachometer
The encoders and the tachometers give the speed feedback to the regulation. They have to be mounted on the
motor shaft with joints without gaps. The best regulation results are possible by using incremental sinusoidal
encoders; it is also possible to use digital incremental encoders or tachogenerators, see section, “Accuracy”.
Features:
Sinusoidal encoder
max frequency
150 kHz
number of pulses per revolution
min
600
max
9999
channel
two-channel
supply
+ 5V (internal supply)
load capacity
> 8.3 mA pp each channel
Digital encoder
max frequency
150 kHz
number of pulses per revolution
min
600
max
9999
channels
two-channel, with complementary outputs
supply
+ 5V / 15 ... 24V (external supply)
+ 24V (internal supply)
load capacity
> 4.5 mA / 6.8 ... 10.9 mA each channel
Analog tachometer
for 6KDV3...Q2...
DC tacho (recommended), rectified AC tacho
for 6KDV3...Q4...
DC tacho only
max voltage at max speed
22.7 / 45.4 / 90.7 / 181.6 / 302.9 V, depending on the
dip switch S4 setting
current
8 mA, full scale
