GEI-100332Ga
——— FUNCTION DESCRIPTION ———
6
4
6.1.1 Enable drive
DRIVE STATUS
START UP
TUNING
MONITOR
[314] Enable drive
Parameter No.
Value
Standard
Configuration min max
Factory
American
Factory
European
Enable drive
Enabled
Disabled
314 0 1 Disabled Disabled Terminal 12
+15 ... 30 V
0 V
The Enable drive command activates the DV-300 Drive.
An auxiliary contact on the AC Input contactor may be wired in the Drive enable (terminal 12).
When the Enable drive=disable and terminal 12 = 0V, no other control commands (e.g. Jog +, Jog - or Start)
are accepted.
Removal of the Enable drive command (Enable drive=disable) while the drive is running causes the motor
coasting to stop. Neither electrical braking nor controlled stopping of the motor within a prescribed time during
the run down are possible. The actuation of the Drive is disabled.
When operated via the keypad the Enable drive command is provided in the DRIVE STATUS, START UP,
TUNING and MONITOR menu.
Using Enable drive command from keypad (mains command=Digital), active voltage level is also required
on terminal 12.
Using Enable drive command from terminal 12 set “Main command=terminals”.
Enable drive in the menu is read only parameter.
