Output voltage
The below mentioned output voltages take into account an AC input undervoltage within the stated tolerance
limits and a voltage drop of 4% due to the inserted AC input reactors. It is the same as the rated armature voltage
suggested for the connected motor.
Armature circuit
Table 2.4.3.3: Armature circuit output votages
AC input voltage Output Armature voltage (Terminals C / D)
(Terminals U / V / W) Two quadrant converter Four quadrant converter
230 V ±10 %, 3Ph 260 V 240 V
400 V ±10 %, 3Ph 470 V * 420 V *
440 V ±10%, 3Ph 530 V 460 V
460 V ±10%, 3Ph 560 V 480 V
480 V ±10%, 3Ph 580 V 500 V
GD0080g
* Voltage measured as per DIN 40 030 (09/93)
As for 6KDV3...Q2C / Q4G converters see Appendix A (GEI-100332C).
Field circuit
Table 2.4.3.4: Field circuit output votages
AC input voltage Output field voltage** (Terminals C1/D1)
(Terminals U1 / V1) Fixed field Adjustable field
230 V ±15 %, 1Ph 200 V * 200 V *
400 V ±15 %, 1Ph 310 V * 310 V *
460 V ±10%, 1Ph 360 V 360 V
GD0080g
* Voltage measured as per DIN 40 030 (09/93)
** The max field voltage is equal to 0.85 x AC input line voltage
n
ote
! The minimum AC input voltage supply value for the field circuit is 110VAC.
As for 6KDV3...Q2C / Q4G converters see Appendix A (GEI-100332C).
