GEI-100332Ga
——— DESCRIPTION, COMPONENT IDENTIFICATION AND SPECIFICATIONS ———
2
18
2.6 WATT LOSS
The power dissipation on the converter side depends on the AC input voltage. The values of the dissipated pow-
ers stated in the following table refer to the functioning with rated current.
n
ote
! The mounting should take into consideration a free space above and below the device of at
least 6 inches (150 mm). (Air circulation).
Starting from the type 560 / 770 A (American / European), the fans must be supplied from the outside with a
single-phase voltage of 230V 50/60 Hz (terminals U3 & V3).
American European Power loss
[W]
Fans Enclosure
Voltage
Pv[V]
Rated current
[A]
Air capacity
[m 3 /h]
ventilation area
[mm 2 ] [in. 2 ]
6KDV3017... 6KDV3020... 131 - - - 2 x 5100 2 x 7.91
6KDV3035... 6KDV3040... 186 - - - 2 x 5100 2 x 7.91
6KDV3056... 6KDV3070... 254
Internal power supply
80 2 x 5100 2 x 7.91
6KDV3088... 6KDV3110... 408 160 2 x 11300 2 x 17.53
6KDV3112... 6KDV3140... 476 160 2 x 11300 2 x 17.53
6KDV3148... 6KDV3185... 553 160 2 x 11300 2 x 17.53
6KDV3224... 6KDV3280... 781 320 2 x 22600 2 x 35.06
6KDV3280... 6KDV3350... 939 320 2 x 22600 2 x 35.06
6KDV3336... 6KDV3420... 1038 320 2 x 22600 2 x 35.06
6KDV3400... 6KDV3500... 1248 320 2 x 22600 2 x 35.06
6KDV3450... 6KDV3650... 1693 680 2 x 35400 2 x 54.91
6KDV3560... 6KDV3770... 2143 230 0.75 1050 2 x 53100 2 x 82.37
6KDV3800... 6KDV310H... 2590 230 0.75 1050 2 x 53100 2 x 82.37
6KDV3850... 2590 230 0.75 1050 2 x 53100 2 x 82.37
GD0100g
Table 2.6.1: Power Dissipation
* When the Drive is mounted in a cabinet, door filters are required to meet pollution degree II ratings for UL.
