GEI-100332Ga
——— PARAMETER LISTS ———
10
18
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
I/O CONFIG \ Analog outputs \ Analog output 1
Select output 1
OFF
Speed ref 1
Speed ref 2
Ramp ref 1
Ramp ref 2
Ramp ref
Speed ref
Ramp out
Actual speed
T current ref 1
T current ref 2
T current ref
Speed reg out
Motor current
Output voltage
Analog input 1
Analog input 2
Analog input 3
Flux current
(Field curr)
Pad 0
Pad 1
Pad 4
Pad 5
Flux reference
(Field reference)
Pad 6
PID output
Out vlt level
Flux current max
(Max field curr)
F act spd
F T curr
Speed draw out
Output power
Roll diameter
Act tension ref
Torque current
W reference
Actual comp
Brake current
66 U16 0 94 Actual
speed (8)
Actual
speed (8)
ü R/Z
0
1
2
3
4
5
6
7
8
9
10
11
15
16
20
24
25
26
27
31
32
33
34
35
38
39
79
80
81
82
84
88
89
90
91
92
93
94
- -
Scale output 1 62 Float -10.000 +10.000 0.000 0.000 ü R/W -
I/O CONFIG \ Analog outputs \ Analog output 2
Select output 2
(Select like output 1)
67 U16 0 94 Motor
current
(16)
Motor
current
(16)
ü R/Z - -
Scale output 2 63 Float -10.000 +10000 0.000 0.000 ü R/W - -
I/O CONFIG \ Analog outputs \ Analog output 3
Select output 3
(Select like output 1)
68 U16 0 94 Flux
-27
Flux
-27
ü R/Z - -
Scale output 3 64 Float -10.000 +10000 0.000 0.000 ü R/W - -
I/O CONFIG \ Analog outputs \ Analog output 4
Select output 4
(Select like output 1)
69 U16 0 94 Output
voltage
(20)
Output
voltage
(20)
ü R/Z - -
Scale output 4 65 Float -10.000 +10000 0.000 0.000 ü R/W - -
