GEI-100332Ga
——— FUNCTION DESCRIPTION ———
6
32
6.7.1 Speed regulator
SPEED REGULAT
[118] Speed ref [rpm]
[236] Speed reg output [% ]
[322] Lock speed reg
[242] Enable spd reg
[348] Lock speed I
[1016] Aux spd fun sel
[444] Prop filter [ms]
Parameter description No.
Value
Standard
Configuration min max
Factory
American
Factory
European
Speed ref [rpm] 118 -32768 +32767 - - **
Speed reg output [% ] 236 -200 +200
see 6.7.1
- - T current ref 1 **
Lock speed reg
ON (1)
OFF (0)
322 0 1 OFF OFF *
Enable spd reg
Enable (1)
Disable (0)
242 0 1 Enabled Enabled -
Lock speed I
Active (0)
Not active (1)
348 0 1 Not active (1) Not active (1) *
Aux spd fun sel
Speed up (0)
Inertia-loss cp (1)
1016 0 1 Speed up (0) Speed up (0)
Prop filter [ms] 444 0 1000 0 0
* This function can be assigned to one of the programmable digital inputs.
** This parameter can be assigned to a programmable analog output.
Speed ref Total speed reference value in rpm
Speed reg output Output value of the speed regulator, used as the reference value for the current regulator
n
ote
! The speed regulator is still active even if disabled (Enable spd reg = Disabled),
therefore the Speed reg output contains valid information also in this case.
Such a data can be transferred to the 6KCV300DGF board to be used for other
regulation. If the speed regulator is enabled (Enable spd reg = Enabled) the
Speed reg output contains the sum of the actual speed regulator output and
T current ref 2.
Lock speed reg This parameter is used in order to lock the speed regulator. When this happens, it stops to
work, the current reference value is set to zero and the drive comes to a stop. This coast-
ing time then depends on the rotating mass and the friction within the system concerned.
If the connection between the speed regulator and the current regulator is restored, the
drive will restart in the shortest possible time.
ON Speed regulator locked (= 0 V when using a digital input).
OFF Speed regulator unlocked (= 15...30 V when using a digital input).
Enable spd reg This parameter can only be changed when the drive is switched off.
Enabled The speed regulator is enabled. The regulator output is connected
to the input of the current regulator. Speed reg output = T cur-
rent ref 1
Disabled The speed regulator is disabled.
