GEI-100332Ga
——— PARAMETER LISTS ———
10
56
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
Enable PD PID
Enabled
Disabled
770 U16 0 1 Disable Disable ü R/W
1
0
ID R/W
PI output PID 771 I16 0 1000 x
PI top
limit
1000 1000 ü R - R
PID out sign PID
Positive
Bipolar
772 U16 0 1 1 1 ü R/W
0
1
- -
PID out scale 773 Float -100.000 +100.000 1.000 1.000 ü R/W - -
PID output 774 I16 -10000 +10000 0 0 ü R QA R
PI central v1 776 Float PI bot-
tom lim
PI top
lim
1.00 1.00 ü R/W - -
PI central v2 777 Float PI bot-
tom lim
PI top
Lim
1.00 1.00 ü R/W - -
PI central v3 778 Float PI bot-
tom lim
PI top
Lim
1.00 1.00 ü R/W IA -
PI central v sel 779 U16 0 3 1 1 ü R/W ID R/W
PI central vs0 780 U16 0 1 1 1 - R/W ID R/W
PI central vs1 781 U16 0 1 0 0 - R/W ID R/W
PID target 782 U16 0 65535 0 0 ü R/W - -
PI integr freeze
OFF
ON
783 U16 0 1 0 0 ü R/W
0
1
ID R/W
PI top lim 784 Float PI bot-
tom lim
10.00 10.00 10.00 ü R/W - -
PI bottom lim 785 Float -10.00 PI top 0.0 0.0 ü R/W - -
lim
PID source 786 U16 0 65535 0 0 ü R/W - -
PID source gain 787 Float -100.000 +100.00 1.000 1.000 ü R/W - -
PD P gain 2 PID [%] 788 Float 0.00 100.00 10.00 10.00 ü R/W - -
PD D gain 2 PID [%] 789 Float 0.00 100.00 1.00 1.00 ü R/W - -
PD P gain 3 PID [%] 790 Float 0.00 100.00 10.00 10.00 ü R/W - -
PD D gain 3 PID[%] 791 Float 0.00 100.00 1.00 1.00 ü R/W - -
Input 1 filter [ms] 792 U16 0 1000 0 0 ü R/W - R/W
P init gain PID 793 Float 0.00 100.00 10.00 10.00 ü R/W - -
Diameter calc
Enabled
Disabled
794 U16 0 1 0 0 ü Z/R
1
0
ID R/W
Positioning spd [rpm] 795 I16 -100 +100 0 0 ü R/W - -
Max deviation 796 I16 -10000 +10000 8000 8000 ü R/W - -
Gear box ratio 797 Float 0.001 1.000 1.000 1.000 ü R/W - -
Dancer constant [mm] 798 U16 1 10000 1 1 ü R/W - -
Minimum diameter [mm] 799 U16 1 2000 100 100 ü R/Z - -
Diameter calc st 800 U16 0 1 0 0 - R QD R
Enable ind store
Enabled
Disabled
911 U16 0 1 Disabled
(0)
Disabled
(0)
ü R/W
1
0
- R/W
Ind store ctrl 912 U16 0 65535 0 0 - R/W - R/W
Index storing 913 U32 0 +232-1 0 0 - R - R
I field cnst 40 916 Float 0.0 100.0 40.0 40.0 ü R/Z -
I field cnst 70 917 Float 0.0 100.0 70.0 70.0 ü R/Z -
I field cnst 90 918 Float 0.0 100.0 90.0 90.0 ü R/Z -
Set flux / if 919 U16 0 1 0 0 ü Z/C -
