GEI-100332Ga
——— PARAMETER LISTS ———
10
24
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
Inversion in 1
Enabled
Disabled
1276 U16 0 1 Disabled
(0)
Disabled
(0)
ü R/W
1
0
- -
Digital input 2
(Select like input 1)
138 U16 0 87 OFF (0) OFF (0) ü R/Z - -
Inversion in 2
Enabled
Disabled
1277 U16 0 1 Disabled
(0)
Disabled
(0)
ü R/W
1
0
- -
Digital input 3
(Select like input 1)
139 U16 0 87 OFF (0) OFF (0) ü R/Z - -
Inversion in 3
Enabled
Disabled
1278 U16 0 1 Disabled
(0)
Disabled
(0)
ü R/W
1
0
- -
Digital input 4
(Select like input 1)
140 U16 0 87 OFF (0) OFF (0) ü R/Z - -
Inversion in 4
Enabled
Disabled
1279 U16 0 1 Disabled
(0)
Disabled
(0)
ü R/W
1
0
- -
Digital input 5
(Select like input 1)
141 U16 0 87 OFF (0) OFF (0) ü R/Z - -
Inversion in 5
Enabled
Disabled
1280 U16 0 1 Disabled
(0)
Disabled
(0)
ü R/W
1
0
- -
Digital input 6
(Select like input 1)
142 U16 0 87 OFF (0) OFF (0) ü R/Z - -
Inversion in 6
Enabled
Disabled
1281 U16 0 1 Disabled
(0)
Disabled
(0)
ü R/W
1
0
- -
Digital input 7
(Select like input 1)
143 U16 0 87 OFF (0) OFF (0) ü R/Z - -
Inversion in 7
Enabled
Disabled
1282 U16 0 1 Disabled
(0)
Disabled
(0)
ü R/W
1
0
- -
Digital input 8
(Select like input 1)
144 U16 0 87 OFF (0) OFF (0) ü R/Z - -
Inversion in 8
Enabled
Disabled
1283 U16 0 1 Disabled
(0)
Disabled
(0)
ü R/W
1
0
- -
I/O CONFIG \ Encoder inputs
Select enc 1
OFF
Speed ref 1
Speed ref 2
Ramp ref 1
Ramp ref 2
1020 U16 0 5 OFF
(0)
see 6.12.05
OFF
(0)
see 6.12.05
ü R/Z
0
2
3
4
5
- -
Select enc 2
OFF
Speed ref 1
Speed ref 2
Ramp ref 1
Ramp ref 2
1021 U16 0 5 OFF
(0)
see 6.12.05
OFF
(0)
see 6.12.05
ü R/Z
0
2
3
4
5
- -
