DV-300 Adjustable Speed Drives
——— FUNCTION DESCRIPTION ———
6
199
PROGRAMMING OF ANALOG INPUTS
ANALOG INPUT 1
Tension ref
Tension reference in %;10V (20mA)=100%
I/O CONFIG Menu
————> Analog input
————> Analog input 1
————> Select input 1 Tension ref:
ANALOG INPUT 2 If the parameter Line spd source has to be set on an analog input, as this parameter is
not listed among the high priority parameters, it is necessary to pass through a support
parameter PAD0…PAD15.
Line spd source: 10V (20mA)=100%
Programming of the analog input 2 on PAD 0:
I/O CONFIG Menu
————> Analog input
————> Analog input 2
————> Select input 2 = PAD 0
ANALOG INPUT 3 If the parameter Ref spd source has to be set on an analog input, as this parameter is
not listed among the high priority parameters, it is necessary to pass through a support
parameter PAD0…PAD15.
Ref spd source: 10V (20mA)=100%
Programming of the analog input 2 on PAD 1:
I/O CONFIG Menu
————> Analog input
————> Analog input 3
————> Select input 3 = PAD 1
PROGRAMMING OF DIGITAL INPUTS
DIGITAL INPUT 1
Diam calc Dis:
Disabling of the diameter calculation (see also par. Line speed thr). In case during the
functioning period it is temporarily disabled, the system stores the last calculated value.
This function has to be enabled only if the application requires it.
I/O CONFIG Menu
————> digital input
————> digital input 1: Diam calc Dis:
DIGITAL INPUT 2
Wind/unwind
Winder/unwinder selection. In case the selection is carried out via the digital input: 0V
=Winder, +24V = Unwinder.
