GEI-100332Ga
——— PARAMETER LISTS ———
10
6
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
Test T curr lim [%] 1048 U16 0 S 20 20 ü R/Z - -
Start 1027 U16 0 65535 - - ü C - -
Inertia [kg*m*m*] 1014 Float 0.001 999.999 S S ü R/W - -
Inertia Nw [kg*m*m*] 1030 Float 0.001 999.999 - - ü R - -
Friction [N*m] 1015 Float 0.000 99.999 S S ü R/W - -
Friction Nw [N*m] 1031 Float 0.000 99.99 - - ü R - -
Speed P [%] 87 Float 0.00 100.00 S S ü R/W - -
Speed P Nw [%] 1032 Float 0.00 100.00 - - ü R - -
Speed I [%] 88 Float 0.00 100.00 S S ü R/W - -
Speed I Nw [%] 1033 Float 0.00 100.00 - - ü R - -
Take val 1028 U16 0 65535 - - ü Z/C - -
START UP
Main commands
Terminals
Digitals
252 U16 0 1 Term (0) Term (0) ü R/Z
0
1
- -
Control mode
Local
Bus
253 U16 0 1 Local (0) Local (0) ü R/Z
0
1
- -
Save parameters 256 U16 ü C/W
(1)
- -
TUNING
R&L Search
(Cur reg selftune)
OFF
ON
452 U16 0 1 OFF OFF ü R/Z
0
1
- -
Enable drive
Enabled
Disabled
314 U16 0 1 Disabled Disabled ü R/W
1
0
12
H
L
R/W
1
0
Start/Stop
Start
Stop
315 U16 0 1 Stop
(0)
Stop
(0)
ü R/W
1
0
13
H
L
R/W
1
0
TUNING \ Speed self tune
Fwd-Rev spd tune 1029 U16 1 2 Fwd Fwd ü R/Z - -
Fwd direction Direction Direction 1
Rev direction -1 -1 2
Test T curr lim [%] 1048 U16 0 S 20 20 ü R/Z - -
Start 1027 U16 0 65535 - - ü C - -
Inertia [kg*m*m*] 1014 Float 0.001 999.999 S S ü R/W - -
Inertia Nw [kg*m*m*] 1030 Float 0.001 999.999 - - ü R - -
Friction [N*m] 1015 Float 0.000 99.999 S S ü R/W - -
Friction Nw [N*m] 1031 Float 0.00 99.99 - - ü R - -
Speed P [%] 87 Float 0.00 100.00 S S ü R/W - -
Speed P Nw [%] 1032 Float 0.00 100.00 - - ü R - -
Speed I [%] 88 Float 0.00 100.00 S S ü R/W - -
Speed I Nw [%] 1033 Float 0.00 100.00 - - ü R - -
Take val 1028 U16 0 65535 - - ü Z/C - -
TUNING
Speed P [%] 87 Float 0.00 100.00 S S ü R/W - -
Speed I [%] 88 Float 0.00 100.00 S S ü R/W - -
Prop filter [ms] 444 U16 0 1000 0 0 ü R/W - -
Flux P [%]
(Fld reg P gain [%])
91 Float 0.00 100.00 2.00 2.00 ü R/W - -
Flux I [%]
(Fld reg I gain [%])
92 Float 0.00 100.00 1.00 1.00 ü R/W - -
