DV-300 Adjustable Speed Drives
——— PARAMETER LISTS ———
10
13
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
Speed fbk sel
Encoder 1
Encoder 2
Tacho
Armature
414 U16 0 3 1 1 ü R/Z
0
1
2
3
- R
Encoder 1 state
Encoder Fault
Encoder ok
648 U16 0 1 - R
0
1
QD R
0
1
Enable fbk contr
Enabled
Disabled
457 U16 0 1 Disabled
(0)
Disabled
(0)
ü R/Z
1
0
- -
Enable fbk bypas
Enabled
Disabled
458 U16 0 1 0 0 ü R/Z
1
0
- -
Flux weak speed [%]
(Crossover speed [%])
456 U16 0 100 100 100 ü R/Z - R
Speed fbk error [%] 455 U16 0 100 22 22 ü R/Z - -
Tacho scale 562 Float 0.90 3.00 1.00 1.00 ü R/W - -
Speed offset 563 Float -20.00 +20.00 0.00 0.00 ü R/W - -
Encoder 1 pulses 416 Float * 600 9999 1024 1024 ü R/Z - R
Encoder 2 pulses 169 Float * 150 9999 1000 1000 ü R/Z - R
Refresh enc 1
(Enc 1 loss detect)
Enabled
Disabled
649 U16 0 1 Disabled
(0)
Disabled
(0)
ü R/W
1
0
- -
Encoder 2 state
Encoder Fault
Encoder ok
651 U16 0 1 - R
0
1
QD R
0
1
Refresh enc 2
(Enc 2 loss detect)
Enabled
Disabled
652 U16 0 1 Disabled
(0)
Disabled
(0)
ü R/W
1
0
- -
Enable ind store
Enabled
Disabled
911 U16 0 1 Disabled
(0)
Disabled
(0)
ü R/W
1
0
- R/W
Ind store ctrl 912 U16 0 65535 0 0 - R/W - R/W
Index storing 913 U32 0 +232-1 0 0 - R - R
CONFIGURATION \ Drive type
Drive size [A] 465 U16 0 S S S ü R - R
2B + E
(2Q + rev exciter)
ON (Off)
OFF (On)
201 U16 0 1 0 0 ü R/Z
0
1
-
Size selection
Standard
American
464 U16 0 1 1 1 ü R/Z
0
1
- -
Software version 331 Text ü R - -
Drive type
DV-300...Q2
DV-300...Q4
300 U16 10 11 S S - R
10
11
- R
10
11
CONFIGURATION \ Dimension fact
Dim factor num 50 I32*** 1 65535 1 1 ü R/Z - R
Dim factor den 51 I32*** 1 +231 -1 1 1 ü R/Z - R
Dim factor text 52 Text rpm rpm ü R/Z - -
CONFIGURATION \ Face value fact
Face value num 54 I16 1 +32767 1 1 ü R/Z - R
Face value den 53 I16 1 +32767 1 1 ü R/Z - R
