GEI-100332Ga
——— FUNCTION DESCRIPTION ———
6
216
6.18.2 Speed
DRIVECOM
[44] Speed input var [FF]
[115] Speed ref var [FF]
[119] Act speed value [FF]
[45] Speed base value [FF]
[46] Speed input perc [%]
[116] Percent ref var [%]
[120] Act percentage [%]
Parameter description No.
Value
Standard
Configuration min max
Factory
American
Factory
European
Speed input var [FF] 44 -2 P45 +2 P45 0 0 *
Speed ref var [FF] 115 -32768 +32767 - - **
Act speed value [FF] 119 -32768 +32767 - - ***
Speed base value [FF] 45 1 16383 1500 1500
Speed input perc [%] 46 -32768 +32767 0 0 *
Percent ref var [%] 116 -32768 +32767 **
Act percentage [%] 120 -32768 +32767 ***
* Factory set as Ramp ref and connected to analog input 1 (terminal 1 and 2). See reference values.
** Factory set as Speed ref and connected to the ramp output. See reference values.
*** Factory set as Motor speed and connected to analog output 1. See BASIC MENU.
Speed input var 1st ramp reference value. The value to be entered is based on the factor function
Speed ref var 1st speed reference value. The value to be entered is based on the factor function
Act speed value Speed actual value in the unit specified in the factor function.
Speed base value The Speed base value is given in the unit specified in the factor function. It is the
base value for all speed values given as a percentage (reference values, adaptive speed
regulation ...). A change in this parameter is only possible when the drive is disabled.
(Enable drive = Disabled).
Speed input perc 1st ramp reference value. Defined as a percentage of the Speed base value
Percent ref var 1st speed reference value. Defined as a percentage of the Speed base value
Act percentage Speed actual value as a percentage of the Speed base value
