DV-300 Adjustable Speed Drives
——— PARAMETER LISTS ———
10
7
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
Voltage P [%] 493 Float 0.00 100.00 30.00 30.00 ü R/W - -
Voltage I [%] 494 Float 0.00 100.00 40.00 40.00 ü R/W - -
Save parameters 256 U16 ü C/W
(1)
- -
MONITOR
Enable drive
Enabled
Disabled
314 U16 0 1 Disabled Disabled ü R/W
1
0
12
H
L
R/W
1
0
Start/Stop
Start
Stop
315 U16 0 1 Stop
(0)
Stop
(0)
ü R/W
1
0
13
H
L
R/W
1
0
MONITOR \ Measurements \ Speed \ Speed in DRC [ ]
Ramp ref (d) [FF] 109 I16 -32768 +32767 - - ü R - R
Ramp output (d) [FF] 112 I16 -32768 +32767 - - ü R - R
Speed ref (d) [FF] 115 I16 -32768 +32767 - - ü R - R
Actual spd (d) [FF] 119 I16 -32768 +32767 - - ü R - R
F act spd (d) [FF] 925 I16 -32768 +32767 - - ü R - R
Act spd filter [s] 923 Float 0.001 1.000 0.100 0.100 ü R/W - -
MONITOR \ Measurements \ Speed \ Speed in rpm
Ramp ref (rpm) 110 I16 -32768 +32767 - - ü R QA R
Ramp outp (rpm) 113 I16 -32768 +32767 - - ü R QA R
Speed ref (rpm) 118 I16 -32768 +32767 - - ü R QA R
Actual spd (rpm) 122 I16 -8192 +8192 - - ü R QA R
Enc 1 speed (rpm) 427 I16 -8192 +8192 - - ü R R
Enc 2 speed (rpm) 420 I16 -8192 +8192 - - ü R R
F act spd (rpm) 924 I16 -32768 +32767 - - ü R QA R
Act spd filter [s] 923 Float 0.001 1.000 0.100 0.100 ü R/W - -
MONITOR \ Measurements \ Speed \ Speed in %
Ramp ref (%) 111 Float -200.0 +200.0 - - ü R - -
Ramp output (%) 114 Float -200.0 +200.0 - - ü R - -
Speed ref (%) 117 Float -200.0 +200.0 - - ü R - -
Actual spd (%) 121 Float -200.0 +200.0 - - ü R - -
MONITOR \ Measurements
Mains voltage [V] 466 U16 0 999 - - ü R - -
Mains frequency [Hz] 588 Float 0.0 70.0 - - ü R - -
Output power [Kw] 1052 Float 0.01 9999.99 - - ü R - -
Output voltage [V] 233 Float ** 0 999 - - ü R QA R
Motor current [%] 199 I16 -250 250 - - ü R QA R
F T curr (%) 928 I16 -500 +500 - - ü R QA R
T curr filter [s] 926 Float 0.001 0.250 0.100 0.100 ü R/W - -
T current ref [%] 41 I16 -200 +200 - - ü R QA R
Flux reference [%]
(Field reference [%])
500 Float* 0.0 100.0 - - ü R QA -
Flux current [%]
(Field curr %)
234 Float * 0.0 100.0 - - ü R QA R
Flux current (A)
(Field curr amps (A))
351 Float 0.1 99.9 S S ü R - -
MONITOR \ I/O
Digital I/Q - - ü - - -
Dig input term 564 U16 0 65535 - - - R - R
Dig input term 1 565 U16 0 1 - - - R - R
Dig input term 2 566 U16 0 1 - - - R - R
