DV-300 Adjustable Speed Drives
——— PARAMETER LISTS ———
10
33
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
OPTIONS \ PID \ PD control
PD P gain 1 PID [%] 768 Float 0.00 100.00 10.00 10.00 ü R/W - -
PD D gain 1 PID [%] 766 Float 0.00 100.00 1.00 1.00 ü R/W - -
PD P gain 2 PID [%] 788 Float 0.00 100.00 10.00 10.00 ü R/W - -
PD D gain 2 PID [%] 789 Float 0.00 100.00 1.00 1.00 ü R/W - -
PD P gain 3 PID [%] 790 Float 0.00 100.00 10.00 10.00 ü R/W - -
PD D gain 3 PID[%] 791 Float 0.00 100.00 1.00 1.00 ü R/W - -
PD D filter PID [ms] 767 U16 0 1000 0 0 ü R/W - -
PD output PID 421 I16 -10000 +10000 0 0 ü R - -
PID out sign PID
Positive
Bipolar
772 U16 0 1 1 1 ü R/W
0
1
- -
PID output 774 I16 -10000 +10000 0 0 ü R QA R
OPTIONS \ PID \ PID target
PID target 782 U16 0 65535 0 0 ü R/W - -
PID out scale 773 Float -100.000 -100.000 1.000 1.000 ü R/W - -
OPTIONS \ PID \ Diameter calc
Diameter calc
Enabled
Disabled
794 U16 0 1 0 0 ü Z/R
1
0
ID R/W
Positioning spd [rpm] 795 I16 -100 +100 0 0 ü R/W - -
Max deviation 796 I16 -10000 +10000 8000 8000 ü R/W - -
Gear box ratio 797 Float 0.001 1.000 1.000 1.000 ü R/W - -
Dancer constant [mm] 798 U16 1 10000 1 1 ü R/W - -
Minimum diameter [cm] 799 U16 1 2000 1 1 ü R/W - -
OPTIONS \ PID
PI central vs0 780 U16 0 1 1 1 - R/W ID R/W
PI central vs1 781 U16 0 1 0 0 - R/W ID R/W
Diameter calc st 800 U16 0 1 0 0 - R QD R
OPTIONS \ TORQUE WINDER
Torque winder En
Enabled
Disabled
1209 U16 0 1 Disabled
0
Disabled
0
ü R/W
1
0
ID R/W
OPTIONS \ TORQUE WINDER \ Diam Calculatio
Roll diameter [m] 1154 Float 0.000 32.000 ü R QA -
Line speed [%] 1160 Float 0.00 200.00 ü R - -
Ref line speed [%] 1286 Float 0.00 200.00 ü R - -
Diam calc Dis
ON
OFF
1161 U16 0 1 ON
(1)
ON
(1)
ü R/W
1
0
ID R/W
Diam inc/dec En
Enabled
Disabled
1205 U16 0 1 Enabled
(0)
Enabled
(0)
ü R/W
1
0
ID R/W
Wind/unwind
Unwinder
Winder
1187 U16 0 1 Winder
(0)
Winder
(0)
ü R/W
1
0
ID R/W
Minimum diameter [mm] 799 U16 1 2000 100 100 ü R/Z - -
Maximum diameter [m] 1153 Float 0.000 32.000 1.000 1.000 ü R/Z - -
Line spd source 1204 U16 0 65535 0 0 ü R/Z - -
Ref spd source 1284 U16 0 65535 0 0 ü R/Z - -
Line speed gain 1156 I16 0 32767 0 0 ü R/W - -
