GEI-100332Ga
——— FUNCTION DESCRIPTION ———
6
178
Parameter description
No.
Value
Standard
Configuration
min
max
Factory
American
Factory
European
Roll diameter [m]
1154
0.000
32.000
****
Line speed [%]
1160
0.00
200.00
Ref line speed [%]
1286
0.00
200.00
Diam calc Dis
ON (1) / OFF (0)
1161
0
1
ON (1)
ON (1)
*
Diam inc/dec En
Enabled (1) / Disabled (0)
1205
0
1
Enabled (0)
Enabled (0)
*
Wind/unwind
Unwinder (1) / Winder (0)
1187
0
1
Winder (0)
Winder (0)
*
Minimum diameter [mm]
799
1
2000
100
100
Maximum diameter [m]
1153
0.000
32.000
1.000
1.000
Line spd source
1204
0
65535
0
0
Ref spd source
1284
0
65535
0
0
Line speed gain
1156
0
32767
0
0
Ref speed gain
1285
0
32767
0
0
Base omega [rpm]
1163
0
8191
1500
1500
Ref speed thr [%]
1155
0
150.00
5
5
Diam filter [ms]
1162
0
5000
100
100
Diam init filter [ms]
1206
0
5000
100
100
Diam stdy delay [ms]
1207
0
60000
0
0
Diam reset
1157
0
1
0
0
*
Diam thr [%]
1158
0
150.00
10
10
Diam reached
1159
0
1
**
Diam preset sel
1168
0
3
0
0
*
Diam preset 0 [m]
1164
0.000
32.000
0
0
Diam preset 1 [m]
1165
0.000
32.000
0
0
Diam preset 2 [m]
1166
0.000
32.000
0
0
Diam preset 3 [m]
1167
0.000
32.000
0
0
***
* This parameter can be set on a programmable digital input.
** This parameter can be set on a programmable digital output.
*** This parameter can be set on a programmable analog input.
**** This parameter can be set on a programmable analog output.
The inputs received by the diameter calculator are the angular speed of the controlled motor and the line speed.
The latter can be measured through an analog input or an encoder.
The value of the calculated diameter can be sent to an analog output; via a digital output it is also possible to
state the overcoming of a programmable threshold.
It is possible to select four values of the starting diameters; one value can derive from an analog input.
Roll diameter
Monitor of the calculated diameter in [m].
Line speed
Monitor of the line speed in [%].
Ref line speed
Reference monitor for the line speed in [%].
Diam calc Dis
Disabling of the diameter calculation (see also par. Ref speed thr). In case such func-
tion is temporarily disabled during the functioning period, the system stores the last
calculated value.
Diam inc/dec En
If enabled and if winder, the calculated diameter can never decrease; if unwinder the
calculated diameter can never increase. It is used to improve the system stability.
Wind/unwind
Winder/unwinder selection. If the selection is carried out via a digital input: 0V = winder,
+24V = unwinder.
