DV-300 Adjustable Speed Drives
——— PARAMETER LISTS ———
10
41
Parameter
No.
Format
Value
Access via
min
max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
Speed P base [A/rpm]
93
Float
000.1
S
0.3 x
P93max
P93max
0.3 x
P93max
P93max
ü
R/Z
-
-
Speed I base [A/rpm·ms]
94
Float
0.001
S
0.3
P94max
0.3
P94max
ü
R/Z
-
-
“Flux P base
(Fld reg PG base)”
97
Float
1
32767
3277
3277
ü
R/Z
-
-
“Flux I Base
(Fld reg IG base)”
98
Float
1
32767
3277
3277
ü
R/Z
-
-
Speed P in use [%]
99
Float
0.00
100.00
S
S
ü
R
-
-
Speed I in use [%]
100
Float
0.00
100.00
S
S
ü
R
-
-
Spd threshold + [FF]
101
U16
1
32767
1000
1000
ü
R/W
-
-
Spd threshold - [FF]
102
U16
1
32767
1000
1000
ü
R/W
-
-
Threshold delay [ms]
103
U16
0
65535
100
100
ü
R/W
-
-
Set error [FF]
104
U16
1
32767
100
100
ü
R/W
-
-
Set delay [ms]
105
U16
1
65535
100
100
ü
R/W
-
-
Ref 0 level [FF]
106
U16
1
32767
10
10
ü
R/W
-
-
Speed zero level [FF]
107
U16
1
32767
10
10
ü
R/W
-
-
Speed zero delay [ms]
108
U16
0
65535
100
100
ü
R/W
-
-
Ramp ref (d) [FF]
109
I16
-32768
+32767
-
-
ü
R
-
R
Ramp ref (rpm)
110
I16
-32768
+32767
-
-
ü
R
QA
R
Ramp ref (%)
111
Float
-200.0
+200.0
-
-
ü
R
-
-
Ramp output (d) [FF]
112
I16
-32768
+32767
-
-
ü
R
-
R
Ramp outp (rpm)
113
I16
-32768
+32767
-
-
ü
R
QA
R
Ramp output (%)
114
Float
-200.0
+200.0
-
-
ü
R
-
-
Speed ref (d) [FF]
115
I16
-32768
+32767
-
-
ü
R
-
R
Percent ref var [%]
116
I16
-32768
+32767
ü
R
-
R
Speed ref (%)
117
Float
-200.0
+200.0
-
-
ü
R
-
-
Speed ref (rpm)
118
I16
-32768
+32767
-
-
ü
R
QA
R
Actual spd (d) [FF]
119
I16
-32768
+32767
-
-
ü
R
-
R
Act percentage [%]
120
I16
-32768
+32767
ü
R
-
R
Actual spd (%)
121
Float
-200.0
+200.0
-
-
ü
R
-
-
Actual spd (rpm)
122
I16
-8192
+8192
-
-
ü
R
QA
R
Enable spd=0 I
Enabled
Disabled
123
U16
0
1
Disabled
Disabled
ü
R/Z
1
0
-
-
Enable spd=0 R
Enabled
Disabled
124
U16
0
1
Disabled
Disabled
ü
R/Z
1
0
-
-
Enable spd=0 P
Enabled
Disabled
125
U16
0
1
Disabled
Disabled
ü
R/Z
1
0
-
-
Spd=0 P gain [%]
126
Float
0.00
100.00
10.00
10.00
ü
R/W
-
-
