GEI-100332Ga
——— PARAMETER LISTS ———
10
72
Parameter No. Position
Offset input 3 84 I/O CONFIG \ Analog inputs \ Analog input 3
Ok relay funct 412 REG PARAMETERS \ In use values
Ok relay open 195 CONFIGURATION \ Prog alarms \ Failure supply
Ok relay open 356 CONFIGURATION \ Prog alarms \ External fault
Ok relay open 358 CONFIGURATION \ Prog alarms \ Undervoltage
Ok relay open 362 CONFIGURATION \ Prog alarms \ Overvoltage
Ok relay open 364 CONFIGURATION \ Prog alarms \ Overcurrent
Ok relay open 367 CONFIGURATION \ Prog alarms \ Overtemp motor
Ok relay open 370 CONFIGURATION \ Prog alarms \ Heatsink
Ok relay open 387 CONFIGURATION \ Prog alarms \ Hw opt1 failure
Ok relay open 472 CONFIGURATION \ Prog alarms \ Field loss
Ok relay open 477 CONFIGURATION \ Prog alarms \ Speed fbk loss
Ok relay open 635 CONFIGURATION \ Prog alarms \ Bus loss
Ok relay open 640 CONFIGURATION \ Prog alarms \ Opt2 failure
Ok relay open 730 CONFIGURATION \ Prog alarms \ Enable seq err
Ok relay open 1297 CONFIGURATION \ Prog alarms \ Brake fault
Ok relay open 1423 CONFIGURATION \ Prog alarms \ Overspeed
Ok relay open 1434 CONFIGURATION \ Prog alarms \ Delta frequency
Ok relay open 1420 CONFIGURATION \ Prog alarms \ Motor I2t ovrld
Ok relay open 1441 CONFIGURATION \ Prog alarms \ Drive I2t ovrld
Out vlt level 921 FLUX REGULATION
Output offset 491 SPEC FUNCTIONS \ Links \ Link 1
Output offset 560 SPEC FUNCTIONS \ Links \ Link 2
Output offset 1225 SPEC FUNCTIONS \ Links \ Link 3
Output offset 1234 SPEC FUNCTIONS \ Links \ Link 4
Output offset 1243 SPEC FUNCTIONS \ Links \ Link 5
Output offset 1252 SPEC FUNCTIONS \ Links \ Link 6
Output power [kW] 1052 DRIVE STATUS
Output power [Kw] 1052 MONITOR \ Measurements
Output voltage [V] 233 DRIVE STATUS
Output voltage [V] 233 MONITOR \ Measurements
Overcurrent thr [%] 584 START UP \ Alarms
Overcurrent thr [%] 584 CONFIGURATION \ Prog alarms \ Overcurrent
Overld available 406 FUNCTIONS \ Overload contr
Overload current [%] 312 START UP \ Overload contr
Overload current [%] 312 FUNCTIONS \ Overload contr
Overload mode 318 START UP \ Overload contr
Overload mode 318 FUNCTIONS \ Overload contr
Overload state 407 FUNCTIONS \ Overload contr
Overload time [s] 310 START UP \ Overload contr
Overload time [s] 310 FUNCTIONS \ Overload contr
Overspeed thr [rpm] 1426 CONFIGURATION \ Prog alarms \ Overspeed
P init gain PID 793 OPTIONS \ PID \ PI controls
Pad 0 503 SPEC FUNCTIONS \ Pad Parameters
Pad 1 504 SPEC FUNCTIONS \ Pad Parameters
Pad 10 513 SPEC FUNCTIONS \ Pad Parameters
Pad 11 514 SPEC FUNCTIONS \ Pad Parameters
Pad 12 515 SPEC FUNCTIONS \ Pad Parameters
Pad 13 516 SPEC FUNCTIONS \ Pad Parameters
Pad 14 517 SPEC FUNCTIONS \ Pad Parameters
Pad 15 518 SPEC FUNCTIONS \ Pad Parameters
Pad 2 505 SPEC FUNCTIONS \ Pad Parameters
Pad 3 506 SPEC FUNCTIONS \ Pad Parameters
