GEI-100332Ga
——— FUNCTION DESCRIPTION ———
6
44
6.10 REG pARAMETERS
REG PARAMETERS
Percent values
Speed regulator
[87] Speed P [%]
[88] Speed I [%]
[459] Speed P bypass [%]
[460] Speed I bypass [%]
Flux regulator
[91] Flux P [%]
[92] Flux I [%]
Voltage reg
[493] Voltage P [%]
[494] Voltage I [%]
Base values
Speed regulator
[93] Speed P base [A/rpm]
[94] Speed I base [A/rpm·ms]
Flux regulator
[97] Flux P base
[98] Flux I base
Voltage reg
[495] Voltage P base [f%/V]
[496] Voltage I base [f%/V·ms]
In use values
[99] Speed P in use [%]
[100] Speed I in use [%]
Parameter description No.
Value
Standard
Configuration min max
Factory
American
Factory
European
Speed P [%] 87 0.00 100.00 10.00 10.00 -
Speed I [%] 88 0.00 100.00 1.00 1.00 -
Speed P bypass [%] 459 0.00 100.00 10.00 10.00 -
Speed I bypass [%] 460 0.00 100.00 1.00 1.00 -
Flux P [%] 91 0.00 100.00 2.00 2.00 -
Flux I [%] 92 0.00 100.00 1.00 1.00 -
Voltage P [%] 493 0.00 100.00 30.00 30.00 -
Voltage I [%] 494 0.00 100.00 40.00 40.00 -
Speed P base [A/rpm] 93 000.1 S 0.3 x P93max
P93max
0.3 x P93max
P93max
-
Speed I base [A/rpm·ms] 94 0.001 S 0.3
P94max
0.3
P94max
-
Flux P base 97 1 32767 3277 3277 -
Flux I base 98 1 32767 3277 3277 -
Voltage P base [f%/V] 495 0.0100 S S S -
Voltage I base [f%/V·ms] 496 0.01 S S S -
Speed P in use [%] 99 0.00 100.00 S S -
Speed I in use [%] 100 0.00 100.00 S S -
