DV-300 Adjustable Speed Drives
——— PARAMETER LISTS ———
10
11
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
SPEED REGULAT \ Droop function
Droop gain [%] 696 Float 0.00 100.00 0.00 0.00 ü R/W - -
Droop filter [ms] 697 U16 0 1000 0 0 ü R/W - -
Load comp [%] 698 I16 -200 +200 0 0 ü R/W IA R/W
Droop limit [FF] 700 U16 0 2*P45 1500 1500 ü R/W - -
Enable droop
Enabled
Disabled
699 U16 0 1 Disabled
(0)
Disabled
(0)
ü R/W
1
0
ID R/W
1
0
SPEED REGULAT \ Inertia/loss cp
Inertia [kg*m*m] 1014 Float 0.001 999.999 S S ü R/W - -
Friction [N*m] 1015 Float 0.000 99.999 S S ü R/W - -
Torque const [N*m/A] 1013 Float 0.01 99.99 S S ü R - -
Inertia c filter [ms] 1012 U16 0 1000 0 0 ü R/W - -
CURRENT REGULAT
T current ref [%] 41 I16 -200 +200 - - ü R QA R
Motor current [%] 199 I16 -250 250 - - ü R QA R
Mot cur threshld [%] 1430 U16 0 200 100 100 ü R/W - -
Mot cur th delay [ms] 1431 U16 0 65535 1000 1000 ü R/W - -
Arm resistance [ ] 453 Float S S 0.500 0.500 ü R/W - -
Arm inductance [mH] 454 Float S S 4.00 4.00 ü R/W - -
E int [V] 587 I16 -80 +80 - - ü R QA -
R&L Search
(Cur reg selftune)
OFF
ON
452 U16 0 1 OFF OFF ü R/Z
0
1
- -
Zero torque
Active
Not active
353 U16 0 1 Not active
(1)
Not active
(1)
ü R/W
0
1
ID
L
H
R/W
FLUX REGULATION (FIELD CURRENT REGULATION)
Enable flux reg
(Enable field reg)
ON (Enabled)
OFF (Disabled)
497 U16 0 1 Enabled Enabled ü R/W
1
0
ID
H
L
-
Flux reg mode
(Field reg mode)
Constant current
Voltage control
(Field weakening)
External control (OFF)
469 U16 0 2 Const.
current
(0)
Const.
current
(0)
ü R/Z
0
1
2
- -
Enable flux weak
(En min field cmd)
ON (Enabled)
OFF (Disabled)
498 U16 0 1 1 1 ü R/W
1
0
ID
H
L
-
Speed-0 f weak
(Field economy)
ON (Enabled)
OFF (Disabled)
499 U16 0 1 0 0 ü R/W
1
0
- -
Flux reference [%]
(Field reference [%])
500 Float* 0.0 100.0 0.0 0.0 ü R QA -
Flux current [%]
(Field curr %)
234 Float* 0.0 100.0 - - ü R QA R
Out vlt level 921 Float* 0.00 100.0 100.0 100.0 ü R/W IA, QA R/W
