Explanation of parameter tables
In the following pages the parameters list of each menu is shown. For each table the following notes are valid:
“No.” column
Parameter number (decimal). In order to address parameters when a serial line/bus or
the 6KCV300DGF card are used, the user must add 2000H (= decimal 8192) to the
indicated value.
“Value” field
S = value depending on the size of the device.
DRIVE STATUS
Start up parameters status
START UP
Basic commissioning of the drive
TUNING
Drive regulators tuning
MONITOR
Display of reference values, speeed, voltage, current, frequency...
INPUT VARIABLES
Ramp reference, speed reference, current reference
LIMITS
Speed limits, current limits, field current limits
RAMP
Acceleration, deceleration, quick stop, ramp shape
SPEED REGULAT
Configuration of the speed regulator, speed zero logic, speed up , droop function
CURRENT REGULAT
Configuration of the current regulator
FLUX REGULATION
Functioning of the field current regulator
REG PARAMETERS
Parameters for speed, current, field and voltage regulation
CONFIGURATION
Functioning, regulation, encoder type, function factor, programmable alarms, address,
password
I/O CONFIG
Configuration of programmable digital and analog input and output
ADD SPEED FUNCT
Motor capture, adaptive speed regulation, speed control, speed zero
FUNCTIONS
Motopotentiometer, jog function, multi-speed, multi-ramps, overload, stop control, Taper
current function
SPEC FUNCTIONS
Test generator, saving parameters, loading factory settings, signal adaptation, PAD param-
eters
OPTIONS
Access to the optional field bus card (Option1), and the DGF (Option2), PID function
DRIVECOM
Parameter setting for the DRIVECOM profile
SERVICE
Menu, only accessible to service personnel of the manufacturer
