DV-300 Adjustable Speed Drives
——— PARAMETER LISTS ———
10
59
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
Speed match
ON
OFF
1195 U16 0 1 OFF
(0)
OFF
(0)
ü R/W
1
0
ID R/W
Spd match acc [s] 1196 Float 0.30 300.00 83.88 83.88 ü R/W - -
Spd match dec [s] 1197 Float 0.30 300.00 83.88 83.88 ü R/W - -
Offset acc time [s] 1198 Float 0.30 950.00 83.88 83.88 ü R/W - -
W offset [rpm] 1199 I16 0 1000 0 0 ü R/W - -
Spd match gain [%] 1200 U16 0 150 100 100 ü R/W - -
Winder side
Down
Up
1201 U16 0 1 Up
(0)
Up
(0)
ü R/W
1
0
ID R/W
W gain [%] 1202 U16 0 100 0 0 ü R/W - -
Spd match compl 1203 U16 0 1 ü R QD R
Line spd source 1204 U16 0 65535 0 0 ü R/Z - -
Diam inc/dec En
Enabled
Disabled
1205 U16 0 1 Enabled
(0)
Enabled
(0)
ü R/W
1
0
ID R/W
Diam init filter [ms] 1206 U16 0 5000 100 100 ü R/W - -
Diam stdy delay [ms] 1207 U16 0 60000 0 0 ü R/W - -
Close loop comp 1208 I16 -32767 +32767 ü R - -
Torque winder En
Enabled
Disabled
1209 U16 0 1 Disabled
0
Disabled
0
ü R/W
1
0
ID R/W
W target 1210 U16 0 65535 0 0 ü R/Z - -
Acc/dec filter [ms] 1212 U16 0 5000 30 30 ü R/W - -
Actual comp [%] 1213 I16 -200 +200 ü R QD -
Closed loop En
Enabled
Disabled
1214 U16 0 1 Disabled
(0)
Disabled
(0)
ü R/Z
1
0
- R/Z
Speed demand En
Enabled
Disabled
1215 U16 0 1 Disabled
(0)
Disabled
(0)
ü R/W
1
0
- R/W
Spd match torque [%] 1216 U16 0 200 100 100 ü R/W - -
W reference [rpm] 1217 I16 -8192 +8192 ü R QA -
Source 1218 U16 0 65535 0 0 ü R/W - -
Destination 1219 U16 0 65535 0 0 ü R/W - -
Mul gain 1220 Float -10000 +10000 1 1 ü R/W - -
Div gain 1221 Float -10000 +10000 1 1 ü R/W - -
Input max 1222 Float -231 231-1 0 0 ü R/W - -
Input min 1223 Float -231 231-1 0 0 ü R/W - -
Input offset 1224 Float -231 231-1 0 0 ü R/W - -
Output offset 1225 Float -231 231-1 0 0 ü R/W - -
Inp absolute
ON
OFF
1226 U16 0 1 OFF
0
OFF
0
ü R/W
1
0
- -
Source 1227 U16 0 65535 0 0 ü R/W - -
Destination 1228 U16 0 65535 0 0 ü R/W - -
Mul gain 1229 Float -10000 +10000 1 1 ü R/W - -
Div gain 1230 Float -10000 +10000 1 1 ü R/W - -
Input max 1231 Float -231 231-1 0 0 ü R/W - -
