GEI-100332Ga
——— PARAMETER LISTS ———
10
66
Parameter No. Position
Digital output 5 149 I/O CONFIG \ Digital outputs
Digital output 6 150 I/O CONFIG \ Digital outputs
Digital output 7 151 I/O CONFIG \ Digital outputs
Digital output 8 152 I/O CONFIG \ Digital outputs
Dim factor den 51 CONFIGURATION \ Dimension fact
Dim factor den 51 DRIVECOM \ Dimension fact
Dim factor num 50 CONFIGURATION \ Dimension fact
Dim factor num 50 DRIVECOM \ Dimension fact
Dim factor text 52 CONFIGURATION \ Dimension fact
Dim factor text 52 DRIVECOM \ Dimension fact
Dinamic f [%] 1175 OPTIONS \ TORQUE WINDER \ Torque calculat \ Comp calculat
Div gain 487 SPEC FUNCTIONS \ Links \ Link 1
Div gain 556 SPEC FUNCTIONS \ Links \ Link 2
Div gain 1221 SPEC FUNCTIONS \ Links \ Link 3
Div gain 1230 SPEC FUNCTIONS \ Links \ Link 4
Div gain 1239 SPEC FUNCTIONS \ Links \ Link 5
Div gain 1248 SPEC FUNCTIONS \ Links \ Link 6
Drive I2t accum 1439 STARTUP \ Overload contr
Drive I2t accum 1439 FUNCTIONS \ Overload contr
Drive ovrld preal. 1438 STARTUP \ Overload contr
Drive ovrld preal. 1438 FUNCTIONS \ Overload contr
Drive ready 380 -
Drive size [A] 465 CONFIGURATION \ Drive type
Drive type 300 CONFIGURATION \ Drive type
Droop gain [%] 696 SPEED REGULAT \ Droop function
Droop filter [ms] 697 SPEED REGULAT \ Droop function
Droop limit [FF] 700 SPEED REGULAT \ Droop function
E int [V] 587 CURRENT REGULAT
Enab multi rmp 243 FUNCTIONS \ Multi ramp fct
Enab multi spd 153 FUNCTIONS \ Multi speed fct
Enable drive 314 DRIVE STATUS
Enable drive 314 START UP
Enable drive 314 TUNING
Enable drive 314 MONITOR
Enable droop 699 SPEED REGULAT \ Droop function
Enable fbk bypas 458 CONFIGURATION \ Speed fbk
Enable fbk contr 457 START UP \ Speed feedback
Enable fbk contr 457 CONFIGURATION \ Speed fbk
Enable flux reg
(Enable field reg)
497 FLUX REGULATION
Enable flux weak
(En min field cmd)
498 FLUX REGULATION
Enable ind store 911 CONFIGURATION \ Speed fbk
Enable jog 244 FUNCTIONS \ Jog function
Enable motor pot 246 FUNCTIONS \ Motor pot
Enable OPT2 425 OPTIONS \ Option 2
Enable overload 309 START UP \ Overload contr
Enable overload 309 FUNCTIONS \ Overload contr
Enable PD PID 770 OPTIONS \ PID
Enable PI PID 769 OPTIONS \ PID
Enable PI-PD PID 1258 OPTIONS \ PID
Enable ramp 245 RAMP
Enable spd adap 181 ADD SPEED FUNCT \ Adaptive spd reg
