GEI-100332Ga
——— PARAMETER LISTS ———
10
32
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
OPTIONS \ Option 1
Accessible only with optional Field Bus card (see Bus card user manual)
OPTIONS \ Option 2
Menu Accessible only with optional DGFC card (see DGFC card user manual)
Enable OPT2
Enabled
Disabled
425 U16 0 1 Disable Disable ü R/Z
1
0
- -
OPTIONS \ PID
Enable PI PID
Enabled
Disabled
769 U16 0 1 Disable Disable ü R/W
1
0
ID R/W
Enable PD PID
Enabled
Disabled
770 U16 0 1 Disable Disable ü R/W
1
0
ID R/W
Enable PI-PD PID
Enabled
Disabled
1258 U16 0 1 Disabled
0
Disabled
0
- R/W
1
0
ID R/W
OPTIONS \ PID \ PID source
PID source 786 U16 0 65535 0 0 ü R/W - -
PID source gain 787 Float -100.000 +100.00 1.000 1.000 ü R/W - -
Feed-fwd PID 758 I16 -10000 +10000 0 0 ü R IA R
OPTIONS \ PID \ PID references
PID error 759 I16 -10000 +10000 0 0 ü R - R
PID feed-back 763 I16 -10000 +10000 0 0 ü R/W IA R/W
PID offs. Sel
Offset 0
Offset 1
762 U16 0 1 0 0 ü R/W
0
1
ID R/W
PID offset 0 760 I16 -10000 +10000 0 0 ü R/W IA R/W
PID offset 1 761 I16 -10000 +10000 0 0 ü R/W - -
PID acc time 1046 Float 0.0 900.0 0.0 0.0 ü R/W - -
PID dec time 1047 Float 0.0 900.0 0.0 0.0 ü R/W - -
PID clamp 757 I16 -10000 +10000 10000 10000 ü R/W - -
OPTIONS \ PID \ PI controls
PI P gain PID 765 Float 0.00 100.00 10.00 10.00 ü R/W - -
PI I gain PID 764 Float 0.00 100.00 10.00 10.00 ü R/W - -
PI steady thr 695 I16 0 10000 0 0 ü R/W - -
PI steady delay 731 U16 0 60000 0 0 ü R/W - -
P init gain PID 793 Float 0.00 100.00 10.00 10.00 ü R/W - -
I init gain PID 734 Float 0.00 100.00 10.00 10.00 ü R/W - -
PI central v sel 779 U16 0 3 1 1 ü R/W ID R/W
PI central v1 776 Float PI bot-
tom lim
PI top
lim
1.00 1.00 ü R/W - -
PI central v2 777 Float PI bot-
tom lim
PI top
Lim
1.00 1.00 ü R/W - -
PI central v3 778 Float PI bot-
tom lim
PI top
Lim
1.00 1.00 ü R/W IA -
PI top lim 784 Float PI bot-
tom lim
10.00 10.00 10.00 ü R/W - -
PI bottom lim 785 Float -10.00 PI top lim 0.0 0.0 ü R/W - -
PI integr freeze
OFF
ON
783 U16 0 1 0 0 ü R/W
0
1
ID R/W
PI output PID 771 I16 0 1000 x
PI top
limit
1000 1000 ü R - R
Real FF PID 418 I16 -10000 +10000 0 0 ü R/W - R
