DV-300 Adjustable Speed Drives
——— PARAMETER LISTS ———
10
9
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
In use Tcur lim+ [%] 10 U16 0 200 ü R - R
In use Tcur lim- [%] 11 U16 0 200 ü R - R
Current lim red [%] 13 U16 0 200 100 100 ü R/W - R/W
Torque reduct
Not active
Active
342 U16 0 1 Not active
(0)
Not active
(0)
ü R/W
0
1
ID
L
H
R/W
0
1
LIMITS \ Flux limits (Fld curr limits)
Flux current max [%]
(Max field curr [%])
467 U16 P468 100 100 100 ü R/W - R/W
Flux current min [%]
(Min field curr [%])
468 U16 0 P467 5 5 ü R/W - ----
RAMP \ Acceleration
Acc delta speed [FF] 21 U32 0 232-1 100 100 ü R/W - -
Acc delta time [s] 22 U16 0 65535 1 1 ü R/W - -
RAMP \ Deceleration
Dec delta speed [FF] 29 U32 0 232-1 100 100 ü R/W - -
Dec delta time [s] 30 U16 0 65535 1 1 ü R/W - -
RAMP \ Quick stop
QStp delta speed [FF] 37 U32 0 232-1 1000 1000 ü R/W - -
QStp delta time [s] 38 U16 0 65535 1 1 ü R/W - -
RAMP
Ramp shape
Linear
S-Shaped
18 U16 0 1 Linear
(0)
Linear
(0)
ü R/Z
0
1
- -
S shape t const [ms] 19 Float 100 3000 300 300 ü R/W - -
S acc t const [ms] 663 Float 100 3000 300 300 ü R/W - -
S dec t const [ms] 664 Float 100 3000 300 300 ü R/W - -
Ramp +/- delay [ms] 20 U16 0 65535 100 100 ü R/W - -
Fwd-Rev
No direction
Fwd direction
Rev direction
No direction
673 U16 0 3 1 1 ü R/W
0
1
2
3
ID R/W
0
1
2
3
Forward sign 293 U16 0 1 0 0 - R/W ID R/W
Reverse sign 294 U16 0 1 0 0 - R/W ID R/W
Enable ramp
Enabled
Disabled
245 I16 0 1 Enabled
(1)
Enabled
(1)
ü R/Z
1
0
- -
Ramp out = 0
Active
Not active
344 U16 0 1 Not active
(1)
Not active
(1)
ü R/W
0
1
ID
L
H
R/W
0
1
Ramp in = 0
Active
Not active
345 U16 0 1 Not active
(1)
Not active
(1)
ü R/W
0
1
ID
L
H
R/W
Freeze ramp
Active
Not active
373 U16 0 1 Not active
(1)
Not active
(1)
ü R/W
0
1
ID
H
L
R/W
1
0
Ramp +
Acc.CW + Dec. anti-CW
(Acc.clockwise + Dec. anti-
clockwise)
Other states
346 U16 0 1 - - - R
1
0
QD
H
L
R
1
0
