GEI-100332Ga
——— WIRING PROCEDURES ———
4
10
From the R-TPD32-GE regulation card, a 6KCV300 TBO card has been integrated on the regulation section
(terminals from 21 to 42). The integrated card is considered by the device as TBO “A”.
Table 4.4.6 - B: Terminal Assignment (terminals from 21 to 42)
Designation Function I/O Max voltage Max current
21
Analog out 1
Analog output 1
Reference point: Terminal 22
Factory set for Actual speed
O ±10V 5mA
22
COM analog output 1
Reference point of analog output 1 — — —
23
Analog out 2
Analog output 2
Reference point: Terminal 24
Factory set for Motor current
O ±10V 5mA
24
COM analog output 2
Reference of analog output 2 — — —
25
COM digital outputs
COM digital outputs (Terminals 26…29) — — —
26
Digital output 1
Digital output 1
COM: Terminal 25
Factory set for Ramp +
O +30V 50mA
27
Digital output 2
Digital output 2
COM: Terminal 25
Factory set for Ramp -
O +30V 50mA
28
Digital output 3
Digital output 3
COM: Terminal 25
Factory set for Spd threshold
O +30V 50mA
29
Digital output 4
Digital output 4
COM: Terminal 25
Factory set for Overload available
O +30V 50mA
30
Supply digital
output
Supply voltage for digital outputs I +30V
depends on
the load
max 80mA
31
Digital input 1
Digital input 1
COM: Terminal 37
Not Factory set
I +30V
15V/3.2mA
24V/5mA
30V/6.4mA
32
Digital input 2
Digital input 2
COM: Terminal 37
Not Factory set
I +30V
15V/3.2mA
24V/5mA
30V/6.4mA
33
Digital input 3
Digital input 3
COM: Terminal 37
Not Factory set
I +30V
15V/3.2mA
24V/5mA
30V/6.4mA
34
Digital input 4
Digital input 4
COM: Terminal 37
Not Factory set
I +30V
15V/3.2mA
24V/5mA
30V/6.4mA
37
COM digital inputs
COM of the digital inputs (Terminals 31…34) — —
38 … 42 Not used
T0240g
