4.9.2 Fuses selection when the Overload function is activated
> 100% for 60 seconds - European > 150% for 60 seconds - American
The fuses suitable for the max Overload capacity of each converter are listed in the following table.
Table 4.9.2.1: Overload fuses
Converter Code Pieces 400 VAC Input supply 500 VAC Input Supply
6KDV3017
6KDV3020
A 3 Z14gR25 (GRD2/25) Z14gR25 (GRD2/25)
3 Nr. 10 005 07.25 Nr. 10 005 07.25
B* 2 Z14gR32 (GRD2/30) Z14gR32 (GRD2/30)
2 Nr. 10 005 07.30 Nr. 10 005 07.30
6KDV3035
6KDV3040
A 3 Z22gR50 (GRD3/50) Z14gR40 (GRD3/35)
3 Nr. 10 005 07.50 Nr. 10 005 07.35
B* 2 Z22gR63 (GRD3/63) Z22gR50 (GRD3/50)
2 Nr. 10 005 07.63 Nr. 10 005 07.50
6KDV3056
6KDV3070
A 3 Z22gR80 (GRD4/80) S00UF01/80/100A/660V
3 S00UF1/80/80A/660V S00UF01/80/100A/660V
3 S00UF01/80/100A/660V
3 Nr. 20 189 20, 80 A Nr. 20 189 20, 80 A
B* 2 Z22gR100 (GRD4/100) Z22gR100 (GRD4/100)
2 S00UF1/80/100A/660V S00UF1/80/100A/660V
2 S00UF1/80/125A/660V
2 Nr. 20 189 20,100 A Nr. 20 189 20,100 A
6KDV3088
6KDV3110
A 3 S00UF1/80/100A/660V S00UF1/80/100A/660V
3 Nr. 20 189 20.100 Nr. 20 189 20.100
B* 2 S00UF1/80/125A/660V S00UF1/80/125A/660V
2 Nr. 20 189 20.125 Nr. 20 189 20.125
6KDV3112
6KDV3140
A 3 S00UF1/80/160A/660V S00UF1/80/160A/660V
3 Nr. 20 189 20.160 Nr. 20 189 20.160
B* 2 S00UF1/80/200A/660V S00UF1/80/200A/660V
2 Nr. 20 189 20.200 Nr. 20 189 20.200
6KDV3148
6KDV3185
A 3 S00UF1/80/200A/660V S00UF1/80/200A/660V
3 Nr. 20 189 20.200 Nr. 20 189 20.200
B* 2 S00UF1/80/200A/660V S00UF1/80/200A/660V
2 Nr. 20 189 20.200 Nr. 20 189 20.200
6KDV3224
6KDV3280
A 3 S1UF1/110/315A/660V S1UF1/110/315A/660V
3 S1UF1/110/350A/660V S1UF1/110/350A/660V
3 Nr. 20 458 20.315 Nr. 20 458 20.315
B* 2 S2UF1/110/400A/660V S2UF1/110/400A/660V
2 S2UF1/110/400A/660V S2UF1/110/400A/660V
2 Nr. 20 459 20.400 Nr. 20 459 20.400
6KDV3280
6KDV3350
A 3 S1UF1/110/400A/660V S1UF1/110/400A/660V
3 S1UF1/110/450A/660V S1UF1/110/450A/660V
3 Nr. 20 459 20.400 Nr. 20 459 20.400
B* 2 S2UF1/110/500A/660V S2UF1/110/500A/660V
2 S2UF1/110/500A/660V S2UF1/110/500A/660V
2 Nr. 20 459 20.500 Nr. 20 459 20.500
6KDV3336
6KDV3420
A 3 S2UF1/110/500A/660V S2UF1/110/500A/660V
3 Nr. 20 459 20.500 Nr. 20 459 20.500
B* 2 S2UF1/110/630A/660V S2UF1/110/630A/660V
2 Nr. 20 459 20.630 Nr. 20 459 20.630
6KDV3400
6KDV3500
A 3 S2UF1/110/630A/660V S2UF1/110/630A/660V
3 S2UF01/110/710A/660V
3 Nr. 20 459 20.630 Nr. 20 459 20.630
B* 2 S3UF1/110/710A/660V S3UF1/110/710A/660V
2 S3UF1/110/710A/660V S3UF1/110/710A/660V
2 Nr. 20 460 20.710 Nr. 20 460 20.710
