DV-300 Adjustable Speed Drives
——— PARAMETER LISTS ———
10
53
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
Pad B Bit 12 549 U16 0 1 0 0 - R/W QD* -
Pad B Bit 13 550 U16 0 1 0 0 - R/W QD* -
Pad B Bit 14 551 U16 0 1 0 0 - R/W QD* -
Pad B Bit 15 552 U16 0 1 0 0 - R/W QD* -
Source 553 U16 0 65535 0 0 ü R/W - -
Destination 554 U16 0 65535 0 0 ü R/W - -
Mul gain 555 Float -10000 +10000 1 1 ü R/W - -
Div gain 556 Float -10000 +10000 1 1 ü R/W - -
Input max 557 Float -231 231-1 0 0 ü R/W - -
Input min 558 Float -231 231-1 0 0 ü R/W - -
Input offset 559 Float -231 231-1 0 0 ü R/W - -
Output offset 560 Float -231 231-1 0 0 ü R/W - -
Inp absolute
OFF
ON
561 U16 0 1 OFF OFF ü R/W
0
1
- -
Tacho scale 562 Float 0.90 3.00 1.00 1.00 ü R/W - -
Speed offset 563 Float -20.00 +20.00 0.00 0.00 ü R/W - -
Dig input term 564 U16 0 65535 - - - R - R
Dig input term 1 565 U16 0 1 - - - R - R
Dig input term 2 566 U16 0 1 - - - R - R
Dig input term 3 567 U16 0 1 - - - R - R
Dig input term 4 568 U16 0 1 - - - R - R
Dig input term 5 569 U16 0 1 - - - R - R
Dig input term 6 570 U16 0 1 - - - R - R
Dig input term 7 571 U16 0 1 - - - R - R
Dig input term 8 572 U16 0 1 - - - R - R
Dig input term 9 573 U16 0 1 - - - R - R
Dig input term 10 574 U16 0 1 - - - R - R
Dig input term 11 575 U16 0 1 - - - R - R
Dig input term 12 576 U16 0 1 - - - R - R
Dig input term 15 579 U16 0 1 - - - R - R
Dig input term 16 580 U16 0 1 - - - R - R
Dig output term 581 U16 0 65535 - - R - R
Virtual dig inp 582 U16 0 65535 - - ü R - -
Virtual dig out 583 U16 0 65535 - - ü R - -
Overcurrent thr [%] 584 U16 0 200 160 160 ü R/W - -
Restart time [ms] 585 U16 0 10000 0 0 ü R/W - -
Hold off time [ms] 586 U16 0 10000 0 0 ü R/W - -
E int [V] 587 I16 -80 +80 - - ü R QA -
Mains frequency [Hz] 588 Float 0.0 70.0 - - ü R - -
Stop mode
OFF
Stop & speed 0
Fast stp & spd 0
Fst / stp & spd 0
626 U16 0 3 Stop &
Speed 0
Stop &
Speed 0
ü R/Z
0
1
2
3
- -
Spd 0 trip delay [ms] 627 U16 0 40000 0 0 ü R/W - -
Trip cont delay [ms] 628 U16 0 40000 0 0 ü R/W - -
Relay 2
(Select like output 1)
629 U16 0 77 Stop ctrl
(23)
Stop ctrl
(23)
ü R/Z - -
Jog stop control
OFF
ON
630 U16 0 1 OFF OFF ü R/Z
0
1
- -
