DV-300 Adjustable Speed Drives
——— CONVERTER OPERATION ———
5
35
5.3 COMMISSIONING
W
arning
!
The safety instructions, danger warnings and technical data in Section 1 and 2 of this manual
must be observed!
D
efinitions
:
Positive speed is clockwise rotation seen from the motor shaft end side.
Negative Speed is counter-clockwise rotation seen from the motor shaft end side.
Positive torque is torquw in clockwise directionseen from the motor shaft end side.
Negative torque is torque in counter-clockwise direction seen from the motor shaft end side.
5.3.1 Setting jumpers and switch
The hardware configuration set via the jumpers and switches on the R-TPD32-GE regulator card must be adapted
to the application at hand and checked before switching on the device.
- Analog inputs 1/2/3
Voltage input 0... 10V
Jumper S9/S10/S11 = OFF
Current voltage 0...20 mA / 4...20 mA
Jumper S9/S10/S11 = ON
Mixed possible configuration
- Adaptation for the speed feedback type
Sinusoidal Encoder
Jumper S5/S6 in position A
Digital Encoder
Jumper S5/S6 any position
Analog tachometer generator
Jumper S5/S6 in position B
Armature reaction
Jumper S5/S6 any position
- Adaptation for the digital encoder voltage
Voltage = 5 V
Jumper S21/S22/S23 = ON
Voltage = 15...30 V
Jumper S21/S22/S23 = OFF
- Control of a digital encoder connected to the connector XE2
Channel C controlled
Jumper S20 = ON
Channel C not controlled
Jumper S20 = OFF
- Adaptation of the max voltage using a tachometer generator:
22.7 / 45.4 / 90.7 / 181.6 / 302.9 V,
depending on the dip switch S4 setting (see chapter 4.4.3)
- Serial interface RS485
On the first and last drop of a line:
Jumper S12 / S13 = ON
On the other converters
Jumper S12 / S13 = OFF
- RS485 serial interface
- divided from the regulation
Jumper S18 / S19 in position OFF
(An external 5 V power supply is needed
on the PINs 5 and 9) see section 4.5.2
- with a common potential 0 V of the regulation
Jumper S18 / S19 in position ON
(Internal power supply)
For further information see section 4.4, “Regulation section”.
