DV-300 Adjustable Speed Drives
——— FUNCTION DESCRIPTION ———
6
47
Parameters Actuation of:
Enable drive
Start
Fast stop
Control mode
selection
Failure reset Save parameters
Main
commands
Control mode
Terminals Local Terminals Keypad /RS485 Terminals of
Keypad
Keypad /RS485
Digital Local Terminals and
keypad/RS485
Keypad /RS485 Terminals of
Keypad
Keypad /RS485
Terminals Bus Terminals Keypad* /
RS485*
or Bus
Terminals or
keypad*
or Bus
Keypad RS485
or Bus
Digital Bus Terminals and
Field Bus
Keypad* /
RS485*
or Bus
Terminals or
keypad*/
RS485*
or Bus
Keypad RS485
or Bus
GD6125g
Parameters Write Access Restrictions
Main
commands
Control mode Terminals Keypad / RS485 Bus
Terminals Local Access to
everything assigned
to programmable
I/Os
Access to all
parameters not
assigned to
programmable I/Os
None
Digital Local Access to
everything assigned
to programmable
I/Os
Access to all
parameters not
assigned to
programmable I/Os
None
Terminals Bus Access to
everything assigned
to programmable
I/Os
- read all
- save parameters
-reset failures*
- select Control mode*
Access to all
parameters not
assigned to
programmable I/Os
Digital Bus Access to
everything assigned
to programmable
I/Os
- read all
- save parameters
-reset failures*
- select Control mode*
Access to all
parameters not
data channel is not
assigned to
programmable I/Os
GD6130g
* Access via the keypad or the RS485 serial interface is protected in this configuration by Password level 1
n
ote
! Write access from Bus through data channel is not affected by Control Mode selection.
