——— PARAMETER LISTS ———
10
38
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
Ramp ref 2 [FF] 48 I16 -2 P45 +2 P45 0 0 ü R/W IA, QA R/W
Ramp ref 2 (%) 49 Float -200.0 +200.0 0.0 0.0 ü R/W - -
Dim factor num 50 I32*** 1 65535 1 1 ü R/Z - R
Dim factor den 51 I32*** 1 231-1 1 1 ü R/Z - R
Dim factor text 52 Text rpm rpm ü R/Z - -
Face value den 53 I16 1 32767 1 1 ü R/Z - R
Face value num 54 I16 1 +32767 1 1 ü R/Z - R
Control word 55 U16 0 65535 ü R/W - R/W
Status word 56 U16 0 65535 ü R - R
Malfunction code
Failure supply
Undervoltage
Overvoltage
Overcurrent
Heatsink
Hardware
DSP error
Interrupt error
Speed fbk loss
External fault
Overtemp motor
Field loss
Bus loss
Hw opt 1 failure
Opt2
Unknown
Enable seq err
57 I16 ü
5100h
3120h
3310h
2300h
4210h
5000h
6110h
6120h
7301h
9000h
4310h
3330h
8110h
7510h
7400h
1001h
9009h
R
5100h
3120h
3310h
2300h
4210h
5000h
6110h
6120h
7301h
9000h
4310h
3330h
8110h
7510h
7400h
1001h
9009h
- -
Generator access
Not connected
T current ref
Flux ref
Ramp ref
Speed ref
58 U16 0 5 Not conn. Not conn. ü R/Z
0
2
3
4
5
- -
Gen frequency [Hz] 59 Float 0.1 62.5 0.1 0.1 ü R/W - -
Gen amplitude [%] 60 Float 0 200.00 0 0 ü R/W - -
Generator offset [%] 61 Float -200.00 +200.00 0 0 ü R/W - -
Scale output 1 62 Float -10.000 +10.000 0.000 0.000 ü R/W -
Scale output 2 63 Float -10.000 +10000 0.000 0.000 ü R/W - -
Scale output 3 64 Float -10.000 +10000 0.000 0.000 ü R/W - -
Scale output 4 65 Float -10.000 +10000 0.000 0.000 ü R/W - -
