DV-300 Adjustable Speed Drives
——— PARAMETER LISTS ———
10
25
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
Encoder 1 pulses 416 Float* 600 9999 1024 1024 ü R/Z - R
Encoder 2 pulses 169 Float* 150 9999 1024 1024 ü R/Z - R
Refresh enc 1
(Enc 1 loss detect)
Enabled
Disabled
649 U16 0 1 Disabled
(0)
Disabled
(0)
ü R/W
1
0
- -
Refresh enc 2
(Enc 2 loss detect)
Enabled
Disabled
652 U16 0 1 Disabled
(0)
Disabled
(0)
ü R/W
1
0
- -
ADD SPEED FUNCT
Auto capture
ON
OFF
388 U16 OFF
(0)
OFF
(0)
ü R/W
1
0
ID
H
L
-
ADD SPEED FUNCT \ Adaptive spd reg
Enable spd adap
Enabled
Disabled
181 U16 0 1 Disabled Disabled ü R/Z
1
0
- -
Select adap type
Speed
Adap reference
Parameter
182 U16 0 2 Speed Speed ü R/Z
0
1
2
- -
Adap reference [FF] 183 I16 -32768 +32767 1000 1000 ü R/W IA R/W
Adap selector 1464 U16 0 3 0 0 ü R/W - -
Adap speed 1 [%] 184 Float 0.0 200.0 20.3 20.3 ü R/W - -
Adap speed 2 [%] 185 Float 0.0 200.0 40.7 40.7 ü R/W - -
Adap joint 1 [%] 186 Float 0.0 200.0 6.1 6.1 ü R/W - -
Adap joint 2 [%] 187 Float 0.0 200.0 6.1 6.1 ü R/W - -
Adap P gain 1 [%] 188 Float 0.00 100.00 10.00 10.00 ü R/W - -
Adap I gain 1 [%] 189 Float 0.00 100.00 1.00 1.00 ü R/W - -
Adap P gain 2 [%] 190 Float 0.00 100.00 10.00 10.00 ü R/W - -
Adap I gain 2 [%] 191 Float 0.00 100.00 1.00 1.00 ü R/W - -
Adap P gain 3 [%] 192 Float 0.00 100.00 10.00 10.00 ü R/W - -
Adap I gain 3 [%] 193 Float 0.00 100.00 1.00 1.00 ü R/W - -
Adap P gain 4 [%] 1462 Float 0.00 100.00 10.00 10.00 ü R/W - -
Adap I gain 4 [%] 1463 Float 0.00 100.00 1.00 1.00 ü R/W - -
ADD SPEED FUNCT \ Speed control
Spd threshold + [FF] 101 U16 1 32767 1000 1000 ü R/W - -
Spd threshold - [FF] 102 U16 1 32767 1000 1000 ü R/W - -
Threshold delay [ms] 103 U16 0 65535 100 100 ü R/W - -
Spd threshold
Speed exceeded
Speed not exceeded
393 U16 0 1 - R
0
1
QD
L
H
R
0
1
Set error [FF] 104 U16 1 32767 100 100 ü R/W - -
Set delay [ms] 105 U16 1 65535 100 100 ü R/W - -
Set speed
Speed not ref. val.
Speed = ref. val.
394 U16 0 1 - R
0
1
QD
L
H
R
0
1
ADD SPEED FUNCT \ Speed zero
Speed zero level [FF] 107 U16 1 32767 10 10 ü R/W - -
Speed zero delay [ms] 108 U16 0 65535 100 100 ü R/W - -
Speed zero thr
Drive not rotating
Drive rotating
395 U16 0 1 - R
0
1
QD
L
H
R
0
1
