GEI-100332Ga
——— PARAMETER LISTS ———
10
58
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
Roll diameter [m] 1154 Float 0.000 32.000 ü R QA -
Ref speed thr [%] 1155 Float 0 150.00 5 5 ü R/W - -
Line speed gain 1156 I16 0 32767 0 0 ü R/W - -
Diam reset 1157 U16 0 1 0 0 ü R/W ID R/W
Diam thr [%] 1158 Float 0 150.00 10 10 ü R/W - -
Diam reached 1159 U16 0 1 ü R QD R
Line speed [%] 1160 Float 0.00 200.00 ü R - -
Diam calc Dis
ON
OFF
1161 U16 0 1 ON
(1)
ON
(1)
ü R/W
1
0
ID R/W
Diam filter [ms] 1162 U16 0 5000 100 100 ü R/W - -
Base omega [rpm] 1163 U16 0 8191 1500 1500 ü R/W - -
Diam preset 0 [m] 1164 Float 0.000 32.000 0 0 ü R/W - -
Diam preset 1 [m] 1165 Float 0.000 32.000 0 0 ü R/W - -
Diam preset 2 [m] 1166 Float 0.000 32.000 0 0 ü R/W - -
Diam preset 3 [m] 1167 Float 0.000 32.000 0 0 ü R/W IA -
Diam preset sel 1168 U16 0 3 0 0 ü R/W ID -
Variable J comp [%] 1171 Float 0.00 199.99 0 0 ü R/W - -
Constant J comp [%] 1172 Float -100.00 +100.00 0 0 ü R/W - -
Mat width [%] 1173 Float 0.00 100.00 100 100 ü R/W - -
Static f [%] 1174 Float 0.00 199.99 0 0 ü R/W - -
Dinamic f [%] 1175 Float 0.00 199.99 0 0 ü R/W - -
Taper enable
Enabled
Disabled
1176 U16 0 1 Disabled
(0)
Disabled
(0)
ü R/W
1
0
ID R/W
Init diameter [m] 1177 Float 0.000 32.000 0.1 0.1 ü R/W - -
Final diameter [m] 1178 Float 0.000 32.000 1 1 ü R/W - -
Tension red [%] 1179 Float 0.00 199.99 0 0 ü R/W IA -
Tension ref [%] 1180 Float 0.00 199.99 0 0 ü R/W IA -
Tension scale [%] 1181 I16 0 200 100 100 ü R/W - -
Time acc/dec min [s] 1182 Float 0.15 300.00 9.01 9.01 ü R/W - -
Int acc calc En
Enabled
Disabled
1183 U16 0 1 Enabled
(1)
Enabled
(1)
ü R/Z
1
0
- -
Line acc [%] 1184 Float 0.00 100.00 100 100 ü R/W - -
Line dec [%] 1185 Float 0.00 100.00 100 100 ü R/W - -
Line fast stop [%] 1186 Float 0.00 100.00 100 100 ü R/W - -
Wind/unwind
Unwinder
Winder
1187 U16 0 1 Winder
(0)
Winder
(0)
ü R/W
1
0
ID R/W
Line acc status 1188 U16 0 1 OFF OFF ü R/W ID R/W
Line dec status 1189 U16 0 1 OFF OFF ü R/W ID R/W
Line fstp status 1190 U16 0 1 OFF OFF ü R/W ID R/W
Act const J comp [%] 1191 Float - 200.00 0 0 ü R - -
Act var J comp [%] 1192 Float - 200.00 0 0 ü R - -
Torque current [%] 1193 Float 0.00 200.00 ü R QA -
Act tension ref [%] 1194 Float 0.00 200.00 0 0 ü R QA -
