DV-300 Adjustable Speed Drives
——— FUNCTION DESCRIPTION ———
6
53
Index storing parameter [13]
No. bit Name Description Access
(Read/Write)
Default
0 Source Enc
Num
It indicates to which encoder the values in this register are referred to:
0 = register data are referred to the Encoder 1
1 = register data are referred to the Encoder 2
R 0
1 MP_IN Actual Qualifier level value:
0 = qualifier input level is low
1 = qualifier input level is high
R 0
2-3 STATNLT Status of the acquisition function:
0 = Switched off
1 = Once, storing is not executed yet
2 = Once, storing is already executed
3 = Continuous
R 0
16-31 CNTNLT Position counter value corresponding to the index. 0 = Switched off
Value is only valid when STANLT is equal to 2 or 3
R 0
Ay6126B
6.11.5 “Standard / American” selection, Software Version
CONFIGURATION
Drive type
[465] Drive size [A]
[201] 2B + E
[464] Size selection
[331] Software version
Parameter description No.
Value
Standard
Configuration min max
Factory
American
Factory
European
Drive size [A] 465 0 S S S -
2B + E
ON (Off) (0)
OFF (On) (1)
201 0 1 0 0 -
Size selection
Standard (0)
American (1)
464 0 1 1 0 -
Software version 331 -
Drive type
DV-300...Q2
DV-300...Q4
300 10 11 S S -
Drive size Display of the converter armature current in ampere (it is codified by the SW15 Switch
placed on the R-TPD32-GE. regulation card). The stated value depends on the setting
of the Size selection parameter.
2B + E Selection of the Q2 + external excitation configuration. Only for Q2 converters. The
function allows the drive to work with an external 4 quadrant field controller. When
the parameter is On the Ramp / Speed / T current references and Speed measurement
have the same behaviour of the Q4 drive.
Size selection With the “Standard” selection the converter produces rated current in a continuative
way in the preset ambient conditions without overload (for overload see 6.14.5). With
“America” selection the rated current is defined considering an overload of 1.5 times for
60 seconds. This causes a reduction of the converter rated current (continuative current)
for the same type of drive. See section 4.4, R-TPD32-GE Regulation card.
Standard The converter produces rated current in a continuative way. It
is stated as Drive size. No overload functions are set.
