DV-300 Adjustable Speed Drives
——— PARAMETER LISTS ———
10
55
Parameter No. Format
Value Access via
min max
Factory
American
Factory
European
Keyp.
RS485/
BUS/
Opt2-M
Term.
Opt2-A/
PDC
PI steady thr 695 I16 0 10000 0 0 ü R/W - -
Droop gain [%] 696 Float 0.00 100.00 0.00 0.00 ü R/W - -
Droop filter [ms] 697 U16 0 1000 0 0 ü R/W - -
Load comp [%] 698 I16 -200 +200 0 0 ü R/W IA R/W
Enable droop
Enabled
Disabled
699 U16 0 1 Disabled
(0)
Disabled
(0)
ü R/W
1
0
ID R/W
1
0
Droop limit [FF] 700 U16 0 2*P45 1500 1500 ü R/W - -
T current lim type
T lim +/-
T lim mot gen
715 U16 0 1 0 0 ü R/Z
0
1
- -
Activity
Ignore
Disable drive
728 U16 0 2 Disable
drive
Disable
drive
ü R/Z
0
2
- -
Latch
ON
OFF
729 U16 0 1 ON ON ü R/Z
1
0
- -
Ok relay open
ON
OFF
730 U16 0 1 ON ON ü R/W
1
0
- -
PI steady delay 731 U16 0 60000 0 0 ü R/W - -
I init gain PID 734 Float 0.00 100.00 10.00 10.00 ü R/W - -
I/n curve
(Taper curr limit)
Enabled
Disabled
750 U16 0 1 0 0 ü R/Z
1
0
- -
“I/n lim 0 [%]
Taper lim 0 [%]”
751 U16 0 200 0 0 ü R/Z - -
“I/n lim 1 [%]
Taper lim 1 [%]”
752 U16 0 200 0 0 ü R/Z - -
“I/n lim 2 [%]
Taper lim 2 [%]”
753 U16 0 200 0 0 ü R/Z - -
“I/n lim 3 [%]
Taper lim 3 [%]”
754 U16 0 200 0 0 ü R/Z - -
“I/n lim 4 [%]
Taper lim 4 [%]”
755 U16 0 200 0 0 ü R/Z - -
Tapered speed [rpm] 756 U16 0 P162 0 0 ü R/Z - -
PID clamp 757 I16 -10000 +10000 10000 10000 ü R/W - -
Feed-fwd PID 758 I16 -10000 +10000 0 0 ü R IA R
PID error 759 I16 -10000 +10000 0 0 ü R - R
PID offset 0 760 I16 -10000 +10000 0 0 ü R/W IA R/W
PID offset 1 761 I16 -10000 +10000 0 0 ü R/W - -
PID offs. Sel
Offset 0
Offset 1
762 U16 0 1 0 0 ü R/W
0
1
ID R/W
PID feed-back 763 I16 -10000 +10000 0 0 ü R/W IA R/W
PI I gain PID 764 Float 0.00 100.00 10.00 10.00 ü R/W - -
PI P gain PID 765 Float 0.00 100.00 10.00 10.00 ü R/W - -
PD D gain 1 PID [%] 766 Float 0.00 100.00 1.00 1.00 ü R/W - -
PD D filter PID [ms] 767 U16 0 1000 0 0 ü R/W - -
PD P gain 1 PID [%] 768 Float 0.00 100.00 10.00 10.00 ü R/W - -
Enable PI PID
Enabled
Disabled
769 U16 0 1 Disable Disable ü R/W
1
0
ID R/W
