General unlocking of the password
ENT
CONFIGURATION
Pword 1: Enabled
Pword 1: Enabled
Password 0 0 0 0 0
+
-
CANC
ENT
Return without changes
0 ... 9
9 ... 0
CONFIGURATION
Pword 1: Disabled
Pword 1: Enabled
Password Wrong
Pword 1: Disabled
Password 0 0 0 0 0
Password ok
Password incorrect
- Select the parameter Pword1 (= Password 1) in the CONFIGURATION menu.
- When the password is enabled, the message “Pword 1: Enabled” appears
- Press ENT to call the value 00000 with the last digit flashing. The value changed is always the digit that is
flashing. The valid password must be re-entered in order to unlock it.
- Increase the numerical value with +
- Reduce the numerical value with -
- Select the next digit left with
- Select the next digit right with
- Confirm the password by pressing ENT. The message: Pword1: Enabled will then appear for a short time.
- The existing password is indicated in the CONFIGURATION menu via the “Pword 1: Enabled” message.
- Press the CANC key in order to abort the entry of the password if required.
- If the incorrect password is entered and then the ENT key pressed, the message “Password wrong” will ap-
pear and the keypad will return to the CONFIGURATION menu with the display “Pword1: Enabled”
n
ote
!
The Save parameter function must be used to save the password if the password itself must
not only be disabled but completely unlocked.
5.1.5 Operating the drive via the Keypad
In order to operate the drive via the keypad, the following settings must be done :
START UP and CONFIGURATION menu
Set Main commands =
Digital
MENU CONFIGURATION
Set Control Mode
=
Local
- The hardware enables on terminals 12...15 are also active when the drive is operated via the keypad. This
means, for example, that the signal at terminal 13 must also be present for starting the drive in adddition to
the command via the keypad.
- If the drive is stopped via the keypad, it can be restarted simply by pressing the Start Key.
